STASTO Allgemeine Preisliste (EUR)
Flanged ball valve with electrical actuator Series BA040 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Other materiales - A03
  5. Flanged ball valve with electrical actuator Series BA040
  6. BA040-40-T0-ABS53-C001-03-C002-31-6-EB0X01
BA040-40-T0-ABS53-C001-03-C002-31-6-EB0X01

BA040-40-T0-ABS53-C001-03-C002-31-6-EB0X01

BA040-40-T0
Flanged ball valve with pneumatic actuator Series BA040; Flange PN16; Body Cast iron EN-GJL-250; Ball 1.4301; Seals PTFE/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+120°C; Pressure range 0...16bar; Nominal diameter 40mm; Length 140mm; Length EN558-1R14; Actuator PAS0855-B; Safety position Open
ABS53-C001-03-C002-31-6
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC
EB0X01
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831613; Contact material Silver-nickel; Material of case Plastic

Intrastat No.: 84818081
Country of origin: Italy
Weight: 12.198 Kg
Short Itemnumber: BA04040T0ABS53C00103C002316EB0X01
https://www.stasto.eu/web/image/product.template/217905/image_1920?unique=0002b3b

BA040-40-T0
flanged ball valve with pneumatic actuator series BA040; flange PN16; body cast iron EN-GJL-250; ball AISI 304; seals PTFE/NBR; single acting actuator; control pressure 5,5...8bar; medium temperature -10...+120°C; pressure range 0...16bar; nominal diameter 40mm; length 140mm; length EN558-1R14; actuator PAS0855-B; safety position open
ABS53-C001-03-C002-31-6
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic

947,96 € 947.96 EUR 947,96 €

price on request

  • Attachment interface VDI/VDE 3845
  • Attachment interface 2 VDI/VDE 3845
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Switch type
  • Design
  • Voltage
  • Switching capacity
  • Pressure range
  • Contact material
  • Material of case
  • Coil
  • Actuator
  • Operating time

This combination does not exist.

Availability:
Contact Us

Share

dimension
Attachment interface VDI/VDE 3845 80x30x20
Attachment interface 2 VDI/VDE 3845 80x30x30
Valve interface Namur 1/4"
DN 40 mm
Length 140 mm
Designs
Connector size 22
Switch type Crouzet 831613
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
Switching capacity 4A/250VAC-1A/24VDC
pressure
Pressure range 0...16 bar
materials
Contact material Silver-nickel
Material of case Plastic
characteristics
Coil C001
Actuator PAS0855

Data sheets, Instructions, 3D-files and Certificates...
