Flanged ball valve with pneumatic actuator BA040-40-T0

Flanged ball valve with pneumatic actuator BA040-40-T0

Flanged ball valve with pneumatic actuator Series BA040; Flange PN16; Body Cast iron EN-GJL-250; Ball 1.4301; Seals PTFE/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+120°C; Pressure range 0...16bar; Nominal diameter 40mm; Length 140mm; Length EN558-1R14; Actuator PAS0855-B; Safety position Open

Intrastat No.: 84818081
Country of origin: Italy
Weight: 11.43 Kg
Short Itemnumber: BA04040T0
https://www.stasto.eu/web/image/product.template/217311/image_1920?unique=477d5fc

flanged ball valve with pneumatic actuator series BA040; flange PN16; body cast iron EN-GJL-250; ball AISI 304; seals PTFE/NBR; single acting actuator; control pressure 5,5...8bar; medium temperature -10...+120°C; pressure range 0...16bar; nominal diameter 40mm; length 140mm; length EN558-1R14; actuator PAS0855-B; safety position open

688,00 € 688.0 EUR 688,00 €

Not Available For Sale

excl. tax
  • Attachment interface VDI/VDE 3845
  • Attachment interface 2 VDI/VDE 3845
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Switch type
  • Design
  • Voltage
  • Switching capacity
  • Pressure range
  • Contact material
  • Material of case
  • Coil
  • Actuator
  • Operating time

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range 0...16 bar
DN 40 mm
Length 140 mm
Documents
Data sheets, drawings and CAD files
Pressure range 0...16 bar
DN 40 mm
Length 140 mm

BA040-40-T0

Documents

2 Documents 7 Languages

Czech / Čeština
ZIP

Data Sheets

1

Declarations of Conformity

1
German / Deutsch
ZIP

Data Sheets

1

Declarations of Conformity

1
English
ZIP

Data Sheets

1

Declarations of Conformity

1
Hungarian / Magyar
ZIP

Data Sheets

1

Declarations of Conformity

1
Polish / Język polski
ZIP

Data Sheets

1

Declarations of Conformity

1
Slovenian / slovenščina
ZIP

Declarations of Conformity

1
Serbian (Latin) / srpski
ZIP

Data Sheets

1

Declarations of Conformity

1
BA040-40-L-01 x 1.0 Pcs
Flanged ball valve BA040-40-L-01
Flanged ball valve Series BA040-L-F; Flange PN16, Full bore; Body Cast iron EN-GJL-250; Ball 1.4301; Seals PTFE/NBR; Pressure range 0...16bar; Medium temperature -10...+120°C; Nominal diameter 40mm; Length 140mm; Length EN558-1R14; Flange ISO5211 F05
PAS0855-B x 1.0 Pcs
PAS0855-B
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Pinion turned by 90°; Diameter 85mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 28,7Nm
RI3009 x 1.0 Pcs
RI3009
Mounting bracket; F07/F05-F05; Bolt 17-10
