BUW6-080-DSN-D22-3C-EB0X01-C0-ABS55-C001-03-C002-31-LV-2

BUW6-080-DSN-D22-3C-EB0X01-C0-ABS55-C001-03-C002-31-LV-2

BUW6-080-DSN-D22-3C
butterfly valve with pneumatic actuator series BUW-DSN-D-3C; wafer type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; nominal flange pressure PN10/16/ANSI150; double acting actuator; control pressure 5,5...8bar; medium temperature -10...+100°C; pressure range 0...10bar; DN 80mm; length 46mm; actuator PAD075; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
EB0X01-C0
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic; with visual position indicator on/off
ABS55
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-Wege-NAMUR-Impulsmagnetventil (NM52W2S-TP); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-LV-2
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 24VAC/DC

Country of origin: Italy
Short Itemnumber: BUW6080DSND223CEB0X01C0ABS55C00103C00231LV2

BUW6-080-DSN-D22-3C
butterfly valve with pneumatic actuator series BUW-DSN-D-3C; wafer type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; nominal flange pressure PN10/16/ANSI150; double acting actuator; control pressure 5,5...8bar; medium temperature -10...+100°C; pressure range 0...10bar; DN 80mm; length 46mm; actuator PAD075; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
EB0X01-C0
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic; with visual position indicator on/off
ABS55
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-Wege-NAMUR-Impulsmagnetventil (NM52W2S-TP); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-LV-2
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 24VAC/DC

826,60 € 826.6 EUR 826,60 €
