Ball valve with pneumatic actuator Series BA078-D0B/D01 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Other materiales - A03
  5. Ball valve with pneumatic actuator Series BA078-D0B/D01
  6. BA078-15-D0B-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360
BA078-15-D0B-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360

BA078-15-D0B-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360

BA078-15-D0B
ball valve with pneumatic actuator series BA078-D0B/D01; butt weld ends; body steel; ball AISI 304; seals PTFE-reinforced/FKM; double acting actuator, oversized; control pressure 5,5...8bar; medium temperature -10...+198°C; nominal diameter 15mm; pressure range steam 0...15bar; length 65mm; actuator PAD052
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
PI16-08-14-N-0-360
swivel male elbow series PI16-360; nickel plated brass; cylindrical thread; diameter 8mm; thread 1/4"

Intrastat No.: 84818081
Country of origin: Italy
Weight: 2.193 Kg
Short Itemnumber: BA07815D0BABS54C00103C002316PI160814N0360
https://www.stasto.eu/web/image/product.template/221067/image_1920?unique=3970b0b

BA078-15-D0B
ball valve with pneumatic actuator series BA078-D0B/D01; butt weld ends; body steel; ball AISI 304; seals PTFE-reinforced/FKM; double acting actuator, oversized; control pressure 5,5...8bar; medium temperature -10...+198°C; nominal diameter 15mm; pressure range steam 0...15bar; length 65mm; actuator PAD052
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
PI16-08-14-N-0-360
swivel male elbow series PI16-360; nickel plated brass; cylindrical thread; diameter 8mm; thread 1/4"

516,10 € 516.1 EUR 516,10 €

price on request

  • Diameter
  • Male thread
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Pressure range Steam
  • Coil
  • Actuator
  • Actuator 2

This combination does not exist.

Availability:
Contact Us

Share

dimension
Diameter 8 mm
Male thread G 1/4"
Valve interface Namur 1/4"
DN 15 mm
Length 65 mm
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...64 bar
Pressure range Steam 0...15 bar
characteristics
Coil C001
Actuator PAD052
Actuator 2 PAS

Data sheets, Instructions, 3D-files and Certificates...
