Short stroke magnetic cylinder SHDM32-15
short stroke magnetic cylinder series SHDM; double acting; pressure range 1...10bar; piston rod with female thread; diameter 32mm; stroke 15mm; piston rod thread M6x1; connection G 1/8"; push force at 6 bar 482N
Intrastat No.: 84123100
Country of origin: Italy
Weight: 0.255 Kg
Short Itemnumber: SHDM3215
Country of origin: Italy
Weight: 0.255 Kg
Short Itemnumber: SHDM3215
short stroke magnetic cylinder series SHDM; double acting; pressure range 1...10bar; piston rod with female thread; diameter 32mm; stroke 15mm; piston rod thread M6x1; connection G 1/8"; push force at 6 bar 482N
| dimension | |
|---|---|
| Diameter | 32 mm |
| Connection | G 1/8" |
| Stroke | 15 mm |
| Piston rod thread | M6x1 |
| function | |
| Function | Double acting |
| pressure | |
| Push force at 6 bar | 482 N |
No spare parts are available for this product.
