SE38-12-SG51
pneumatically operated seat valve; mixing function; 3-way-type; body AISI 316; seal PTFE; female thread; for gaseous media and liquids; medium temperature -30...+170°C; RP 1/2"; DN 15mm; operating pressure 0...8bar; control pressure 5...9bar; diameter actuator 50mm
Intrastat No.: 84818079
Country of origin: Germany
Weight: 1.73 Kg
Short Itemnumber: SE3812SG51
Country of origin: Germany
Weight: 1.73 Kg
Short Itemnumber: SE3812SG51
pneumatically operated seat valve; mixing function; 3-way-type; body AISI 316; seal PTFE; female thread; for gaseous media and liquids; medium temperature -30...+170°C; RP 1/2"; DN 15mm; operating pressure 0...8bar; control pressure 5...9bar; diameter actuator 50mm
| dimension | |
|---|---|
| Female thread | RP 1/2" |
| DN | 15 mm |
| Diameter Actuator | 50 mm |
| pressure | |
| Operating pressure | 0...8 bar |
| Control pressure | 5...9 bar |
| materials | |
| Body | Stainless steel AISI 316 |
| characteristics | |
| Medium temperature | -30...+170 °C |
No spare parts are available for this product.
