  5. Pneumatically operated seat valve Series SE24-ST
  6. SE24-25-ST52-ABS30-C001-22-C002-31-6
SE24-25-ST52-ABS30-C001-22-C002-31-6

SE24-25-ST52-ABS30-C001-22-C002-31-6

SE24-25-ST52
Pneumatically operated seat valve Series SE24-ST; ATEX II 2G Ex h IIC T6…T2 X Gb / II 2D Ex h IIIC 85°C…220°C X Db; NC; Body Stainless steel AISI 316; Seal PTFE; Flange PN40; For liquids; Closing against flow; Medium temperature -30...+170°C; DN 25mm; Operating pressure 0…5,6bar; Control pressure 4,5...10bar; Diameter Actuator 50mm
ABS30
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-Wegemagnetventil (PS125-18-C); Standard coil C001; Connector size 22mm; Actuator 50 mm
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 4.054 Kg
Short Itemnumber: SE2425ST52ABS30C00122C002316
https://www.stasto.eu/web/image/product.template/209108/image_1920?unique=c891e91

SE24-25-ST52
pneumatically operated seat valve series SE24-ST; ATEX II 2G Ex h IIC T6…T2 X Gb / II 2D Ex h IIIC 85°C…220°C X Db; NC; body stainless steel AISI 316; seal PTFE; flange PN40; for liquids; closing against flow; medium temperature -30...+170°C; DN 25mm; operating pressure 0…5,6bar; control pressure 4,5...10bar; diameter actuator 50mm
ABS30
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series SE, pinch valves series PI03, series PI04; 3/2-Wegemagnetventil (PS125-18-C); standard coil C001; connector size 22mm; actuator 50 mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

940,80 € 940.8 EUR 940,80 €

price on request

  • DN
  • Cable length
  • Flange
  • Diameter Actuator
  • Connector size
  • Design
  • Voltage
  • Voltage type
  • Operating pressure
  • Control pressure
  • Coil
  • Actuator
  • Approval

This combination does not exist.

Availability:
Contact Us

Share

dimension
DN 25 mm
Flange PN40
Diameter Actuator 50 mm
Designs
Connector size 22 mm
design
Design ATEX
Electrical key figures
Voltage 230V/50-60Hz
pressure
Operating pressure 0...5,6 bar
Control pressure 4,5...10 bar
characteristics
Coil C001
Actuator 50 mm
