Pneumatically operated seat valve Series SE02-ST; NC; Body Stainless steel AISI 316; Seal PTFE; For liquids; Closing against flow; Medium temperature -30...+220°C; Butt weld ends DIN 11850-2; DN 40mm; Operating pressure 0-7,9bar; Control pressure 3,5-10bar; Diameter Actuator 80mm; Dead-space-free gland installation; High temperature design; Head end gasket Klinger Top-chem-2000; Food application design; wetted materials Conform FDA And EG 1935/2004; Incl. 1 inductive limit switch 10-30VDC; Electrical position indication With cable bushing
Country of origin: Germany
Short Itemnumber: SE02D40ST8103
Pneumatically operated seat valve Series SE02-ST; NC; Body Stainless steel AISI 316; Seal PTFE; For liquids; Closing against flow; Medium temperature -30...+220°C; Butt weld ends DIN 11850-2; DN 40mm; Operating pressure 0-7,9bar; Control pressure 3,5-10bar; Diameter Actuator 80mm; Dead-space-free gland installation; High temperature design; Head end gasket Klinger Top-chem-2000; Food application design; wetted materials Conform FDA And EG 1935/2004; Incl. 1 inductive limit switch 10-30VDC; Electrical position indication With cable bushing
Technical specifications
| Brand | STASTO |
|---|
| Brand | STASTO |
