RAU004-M

NWT63-270 x 1.0

NWT63-270

Profile magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 63mm; Stroke 270mm; Piston rod thread M16x1,5; Connection 3/8"; Push force at 6 bar 1869N

E52W1SM14 x 1.0

5/2-way valve E52W1SM14

5/2-way valve Series E5.; Pilot-operated; Actuation Electrical/spring; Standard coil C001; Connector size 22mm; Connection 1/4"; Nominal diameter 8mm; Pressure range 2,5-10bar; Flow rate 1080Nl/min

Add to Cart

G-50-63-S01 x 1.0

G-50-63-S01

Rod clevis; For cylinder; Thread M16x1,5; Diameter Series NWT, RWS 50, 63mm; Diameter Series NSKU-M 80mm; Clevis spacing Inside 22mm

Add to Cart

3830-3/8" x 1.0

Ball valve made of brass 3830-3/8"

Ball valve made of brass Series 3830; Mini type; Female thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 3/8"; Nominal diameter 8mm; Length 41mm

Add to Cart

TH38C-38-B-Z x 1.0

Detachable hex nipple TH38C-38-B-Z

Detachable hex nipple Series TH38C; Brass; Conical thread; Metal sealing; Thread 3/8"; Thread 3/8"

Add to Cart

PI12-10-38-N-0 x 1.0

Straight male stud fitting PI12-10-38-N-0

Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 3/8"

Add to Cart

PI12-10-14-N-0 x 1.0

Straight male stud fitting PI12-10-14-N-0

Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 1/4"

Add to Cart

SLS-M14-NS x 2.0

Silencer SLS-M14-NS

Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl

Add to Cart

PI16-08-14-N-0-360 x 2.0

Swivel male elbow PI16-08-14-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"

Add to Cart

SCVE14 x 1.0

Valve mounting set

Valve mounting set; For valves Series E5, 1/4"; For cylinder Series NWT; Minimum stroke 100mm;

Add to Cart

PI16-08-38-N-0-360 x 2.0

Swivel male elbow PI16-08-38-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 3/8"

Add to Cart

CP-8/6-BU-1 x 0.5

Plastic hose CP-8/6-BU-1

Plastic hose Series CP; Material Co-polyurethane; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,40; Vacuum -0,87bar; Temperature range -40...100°C; Outside diameter 8mm; Inside diameter 6mm; Operating pressure at 23°C 15bar; Colour Blue

Add to Cart
