Pressure regulator PR120-14-0,3/3-MA

Pressure regulator PR120-14-0,3/3-MA

PR120-14-0,3/3
pressure regulator series PR120; without relieving; inlet pressure max. 60bar; material stainless steel AISI 316L; without manometer; connection 1/4"; flow at 6,3bar/Δp=1bar 4800Nl/min; pressure range 0,3...3bar
4164
bourdon tube manometer; material stainless steel; front glass polycarbonat; ambient temperature -40...+60°C; medium temperature max. +100°C; connection 1/4" rear; class 2,5; diameter 50mm; indicating range 0-4/0-58; unit bar/psi

Stainless Steel.gif
Intrastat No.: 84811099
Country of origin: Italy
Weight: 1.69 Kg
Short Itemnumber: PR120140.33MA
https://www.stasto.eu/web/image/product.template/237487/image_1920?unique=d6c3193

PR120-14-0,3/3
pressure regulator series PR120; without relieving; inlet pressure max. 60bar; material stainless steel AISI 316L; without manometer; connection 1/4"; flow at 6,3bar/Δp=1bar 4800Nl/min; pressure range 0,3...3bar
4164
bourdon tube manometer; material stainless steel; front glass polycarbonat; ambient temperature -40...+60°C; medium temperature max. +100°C; connection 1/4" rear; class 2,5; diameter 50mm; indicating range 0-4/0-58; unit bar/psi

519,20 € 519.2 EUR 519,20 €

Not Available For Sale

excl. tax
  • Connection
  • Pressure range
  • Flow rate at 6.3bar/Δp=1bar

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Connection 1/4"
Pressure range 0,3...3 bar
Flow rate at 6.3bar/Δp=1bar 4800 Nl/min
Connection 1/4"
Pressure range 0,3...3 bar
Flow rate at 6.3bar/Δp=1bar 4800 Nl/min
Pressure regulator PR120-14-0,3/3
PR120-14-0,3/3 x 1.0 Pcs
Pressure regulator PR120-14-0,3/3
pressure regulator series PR120; without relieving; inlet pressure max. 60bar; material stainless steel AISI 316L; without manometer; connection 1/4"; flow at 6,3bar/Δp=1bar 4800Nl/min; pressure range 0,3...3bar
4164
4164 x 1.0 Pcs
4164
Bourdon tube manometer; Material Stainless steel; Front glass Polycarbonat; Ambient temperature -40...+60°C; Medium temperature Max. +100°C; Connection 1/4" Rear; Class 2,5; Diameter 50mm; Indicating range 0-4/0-58; Unit bar/psi
