  6. PI04-34-NZS-51-ABS30-C001-22-C002-31-LV-1
PI04-34-NZS-51-ABS30-C001-22-C002-31-LV-1

PI04-34-NZS-51-ABS30-C001-22-C002-31-LV-1

PI04-34-NZS-51
Pinch valve Series PI04; NO; Connection parts 1.4435; Tube NBR food-safe; Control pressure has to be adjusted acc. to diagram in data-sheet; Medium temperature -20...+80°C; RP 3/4"; DN 20mm; Pressure range 0-6bar; Diameter Actuator 50mm
ABS30
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-Wegemagnetventil (PS125-18-C); Standard coil C001; Connector size 22mm; Actuator 50 mm
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-LV-1
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 2.324 Kg
Short Itemnumber: PI0434NZS51ABS30C00122C00231LV1
https://www.stasto.eu/web/image/product.template/205457/image_1920?unique=ab69362

PI04-34-NZS-51
pinch valve series PI04; NO; connection parts AISI 316L; tube NBR food-safe; control pressure has to be adjusted acc. to diagram in data-sheet; medium temperature -20...+80°C; RP 3/4"; DN 20mm; pressure range 0-6bar; diameter actuator 50mm
ABS30
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series SE, pinch valves series PI03, series PI04; 3/2-Wegemagnetventil (PS125-18-C); standard coil C001; connector size 22mm; actuator 50 mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-LV-1
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 230VAC/DC

894,50 € 894.5 EUR 894,50 €

price on request

  • Female thread
  • DN
  • Cable length
  • Diameter Actuator
  • Connector size
  • Design
  • Voltage
  • Voltage type
  • Pressure range
  • Coil
  • Actuator
  • Approval

This combination does not exist.
