  6. PI04-12-NZS-51-ABS30-C001-22-C002-31-6
PI04-12-NZS-51-ABS30-C001-22-C002-31-6

PI04-12-NZS-51-ABS30-C001-22-C002-31-6

PI04-12-NZS-51
Pinch valve Series PI04; NO; Connection parts 1.4435; Tube NBR food-safe; Control pressure has to be adjusted acc. to diagram in data-sheet; Medium temperature -20...+80°C; RP 1/2"; DN 15mm; Pressure range 0-6bar; Diameter Actuator 50mm
ABS30
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-Wegemagnetventil (PS125-18-C); Standard coil C001; Connector size 22mm; Actuator 50 mm
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 2.054 Kg
Short Itemnumber: PI0412NZS51ABS30C00122C002316
https://www.stasto.eu/web/image/product.template/205450/image_1920?unique=ab69362

PI04-12-NZS-51
pinch valve series PI04; NO; connection parts AISI 316L; tube NBR food-safe; control pressure has to be adjusted acc. to diagram in data-sheet; medium temperature -20...+80°C; RP 1/2"; DN 15mm; pressure range 0-6bar; diameter actuator 50mm
ABS30
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series SE, pinch valves series PI03, series PI04; 3/2-Wegemagnetventil (PS125-18-C); standard coil C001; connector size 22mm; actuator 50 mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

889,20 € 889.2 EUR 889,20 €

price on request

  • Female thread
  • DN
  • Cable length
  • Diameter Actuator
  • Connector size
  • Design
  • Voltage
  • Voltage type
  • Pressure range
  • Coil
  • Actuator
  • Approval

This combination does not exist.

Availability:
Contact Us

Share

dimension
Female thread RP 1/2"
DN 15 mm
Diameter Actuator 50 mm
Designs
Connector size 22 mm
design
Design Standard
Electrical key figures
Voltage 230V/50-60Hz
pressure
Pressure range 0...6 bar
characteristics
Coil C001
Actuator 50 mm

Data sheets, Instructions, 3D-files and Certificates...
