Pinch valve PI03-20-VZS-1252
Pinch valve Series PI03; NC; Connection parts 1.4435; Tube FKM; Medium temperature -10...+130°C; RP 2"; DN 50mm; Pressure range 0...4bar; Control pressure 2,2...10bar; Diameter Actuator 125mm
Intrastat No.: 84818079
Country of origin: Germany
Weight: 8.79 Kg
Short Itemnumber: PI0320VZS1252
Country of origin: Germany
Weight: 8.79 Kg
Short Itemnumber: PI0320VZS1252
pinch valve series PI03; NC; connection parts AISI 316L; tube FKM; medium temperature -10...+130°C; RP 2"; DN 50mm; pressure range 0...4bar; control pressure 2,2...10bar; diameter actuator 125mm
| dimension | |
|---|---|
| Female thread | RP 2" |
| DN | 50 mm |
| Diameter Actuator | 125 mm |
| pressure | |
| Pressure range | 0...4 bar |
| Control pressure | 2,2...10 bar |
No spare parts are available for this product.
