  6. PI03-12-NZS-81-ABS31-BDA08024CS-C003-32-6
PI03-12-NZS-81-ABS31-BDA08024CS-C003-32-6

PI03-12-NZS-81-ABS31-BDA08024CS-C003-32-6

PI03-12-NZS-81
Pinch valve Series PI03; NC; Connection parts 1.4435; Tube NBR food-safe; Medium temperature -20...+80°C; RP 1/2"; DN 15mm; Pressure range 0-6bar; Control pressure 3,5-10bar; Diameter Actuator 80mm
ABS31
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-way solenoid valve (31A3AV20); Standard coil BDA; Connector size 32mm; Actuator 80 mm/125 mm
BDA08024CS
Coil Type BDA; Standard; Connector size 32mm; Voltage 24VDC
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 3.59 Kg
Short Itemnumber: PI0312NZS81ABS31BDA08024CSC003326
https://www.stasto.eu/web/image/product.template/205336/image_1920?unique=ab69362

PI03-12-NZS-81
pinch valve series PI03; NC; connection parts AISI 316L; tube NBR food-safe; medium temperature -20...+80°C; RP 1/2"; DN 15mm; pressure range 0-6bar; control pressure 3,5-10bar; diameter actuator 80mm
ABS31
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series SE, pinch valves series PI03, series PI04; 3/2-way solenoid valve (31A3AV20); standard coil BDA; connector size 32mm; actuator 80 mm/125 mm
BDA08024CS
coil type BDA; standard; connector size 32mm; voltage 24VDC
C003-32-6
connector; connector size 32mm; Standard; voltage 0...250VAC/DC

1.208,80 € 1208.8 EUR 1.208,80 €

price on request

  • Female thread
  • DN
  • Cable length
  • Diameter Actuator
  • Connector size
  • Design
  • Voltage
  • Voltage type
  • Pressure range
  • Control pressure
  • Coil
  • Actuator
  • Approval

This combination does not exist.

Availability:
Contact Us

Share

dimension
Female thread RP 1/2"
DN 15 mm
Diameter Actuator 80 mm
Designs
Connector size 32 mm
design
Design Standard
Electrical key figures
Voltage 24VDC
Voltage type DC
pressure
Pressure range 0...6 bar
Control pressure 3,5...10 bar
characteristics
Coil BDA
Actuator 80 mm/125 mm
Approval CE

Data sheets, Instructions, 3D-files and Certificates...
