Pneumatic actuator PAS1405-VK1411-ABS54-C001-03-C002-31-LV-2

Pneumatic actuator PAS1405-VK1411-ABS54-C001-03-C002-31-LV-2

PAS1405
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 140mm; Flange ISO5211 F10/F12; Female square 27mm; Torque at 5,5bar 114Nm
VK1411
Square adapter Series VK; 14X11; Length 16mm; Material Stahl
ABS54
Mounted pilot valve Series ABS; Speed control; Suitable for Pneumatically operated butterfly valve; Standard coil C001; Connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); Actuator PAD/PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-LV-2
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC

Intrastat No.: 84123900
Country of origin: Italy
Weight: 22.28 Kg
Short Itemnumber: PAS1405VK1411ABS54C00103C00231LV2
