Glycerin manometer MA029-63NB-16
Glycerin manometer Series MA029-B; Bourdon tube manometer; Body Stainless steel 1.4301; Measuring unit 1.4404; Front glass Flat instrument glass; Ambient temperature -40...+60°C; Medium temperature Max. +200°C; Connection Below; Diameter 63mm; Indicating range 0...16; Unit bar; Class 1,6; Connection 1/4"NPT
Intrastat No.: 90262040
Country of origin: Austria
Short Itemnumber: MA02963NB16
Country of origin: Austria
Short Itemnumber: MA02963NB16
glycerin manometer series MA029-B; bourdon tube manometer; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection below; diameter 63mm; indicating range 0...16; unit bar; class 1,6; connection 1/4"NPT
| dimension | |
|---|---|
| Diameter | 63 mm |
| Connection | 1/4" NPT |
| characteristics | |
| Indicating range | 0...16 |
| Unit | bar |
| Class | 1,6 |
No spare parts are available for this product.
