Bourdon tube pressure gauge MA029-50R-2,5 (copy)
bourdon tube manometer series MA029-R; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection rear; diameter 50mm; indicating range 0…2,5; unit bar; connection 1/4"; class 1,6
Intrastat No.: 90262040
Country of origin: Austria
Weight: 0.0 Kg
Short Itemnumber: MA02950R10
Country of origin: Austria
Weight: 0.0 Kg
Short Itemnumber: MA02950R10
bourdon tube manometer series MA029-R; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection rear; diameter 50mm; indicating range 0…2,5; unit bar; connection 1/4"; class 1,6
| dimension | |
|---|---|
| Diameter | 50 mm |
| Connection | 1/4" |
| characteristics | |
| Indicating range | 0...10 |
| Unit | bar |
| Class | 1,6 |
No spare parts are available for this product.
