Bourdon tube manometer MA029-40B-6
Bourdon tube manometer Series MA029-B; Body Stainless steel 1.4301; Measuring unit 1.4404; Front glass Flat instrument glass; Ambient temperature -40...+60°C; Medium temperature Max. +200°C; Connection Below; Diameter 40mm; Indicating range 0...6; Unit bar; Connection 1/4"; Class 1,6
Intrastat No.: 90262040
Country of origin: Austria
Weight: 0.07 Kg
Short Itemnumber: MA02940B6
Country of origin: Austria
Weight: 0.07 Kg
Short Itemnumber: MA02940B6
bourdon tube manometer series MA029-B; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection below; diameter 40mm; indicating range 0...6; unit bar; connection 1/4"; class 1,6
| dimension | |
|---|---|
| Diameter | 40 mm |
| Connection | 1/4" |
| characteristics | |
| Indicating range | 0...6 |
| Unit | bar |
| Class | 1,6 |
No spare parts are available for this product.
