Bourdon tube manometer MA029-100B-1,6
Bourdon tube manometer Series MA029-B; Body Stainless steel 1.4301; Measuring unit 1.4404; Front glass Flat instrument glass; Ambient temperature -40...+60°C; Medium temperature Max. +200°C; Connection Bottom; Diameter 100mm; Indicating range 0...1,6; Unit bar; Connection 1/2"; Class 1
Intrastat No.: 90262040
Country of origin: Austria
Short Itemnumber: MA029100B1.6
Country of origin: Austria
Short Itemnumber: MA029100B1.6
bourdon tube manometer series MA029-R; body stainless steel AISI 304; measuring unit AISI 316L; front glass flat instrument glass; ambient temperature -40...+60°C; medium temperature max. +200°C; connection rear; diameter 100mm; indicating range 0...16; unit bar; connection 1/2"; class 1
| dimension | |
|---|---|
| Diameter | 100 mm |
| Connection | 1/2" |
| characteristics | |
| Indicating range | 0...1,6 |
| Unit | bar |
| Class | 1 |
No spare parts are available for this product.
