4HF25CS-DD-DD-S0T
x 1.0
IWTS006
Weight: 2.57 Kg
Short Itemnumber:IWTS006
No Specifications
TH60-14-12-N
x 1.0
Female to male reducer adapter TH60-14-12-N
Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 1/2"
SLB-14-B
x 1.0
Silencer bushing SLB-14-B
Silencer bushing Series SLB; Sinterbronze; Operating pressure Max. 10bar; Connection 1/4"; Length 19mm
TH50-14-N-0
x 2.0
Plug screw TH50-14-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/4"
TH50-12-N-0
x 1.0
Plug screw TH50-12-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/2"
TH38C-14-38-N
x 1.0
Reduction hex nipple TH38C-14-38-N
Reduction hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/4"; Thread 3/8"
FR-38-20-08-R-PE-SS
x 1.0
Filter regulator FR-38-20-08-R-PE-SS
Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 3/8"; Flow at 6,3bar/Δp=1bar 2100Nl/min; Max. inlet pressure 12,5bar
3830-3/8"
x 1.0
Ball valve made of brass 3830-3/8"
Ball valve made of brass Series 3830; Mini type; Female thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 3/8"; Nominal diameter 8mm; Length 41mm
PI12-10-38-N-0
x 2.0
Straight male stud fitting PI12-10-38-N-0
Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 3/8"
PI12-08-18-N-0
x 8.0
Straight male stud fitting PI12-08-18-N-0
Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/8"
PI16-08-14-N-0-360
x 8.0
Swivel male elbow PI16-08-14-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"
FC04-14-W
x 1.0
banjo flow control valve FC04-14-W
banjo flow control valve series FC04; without banjo; actuation slotted screw/knurled screw fixable; connection 1/4"
TH16C-38-N
x 1.0
Elbow adapter Male thread/Female thread TH16C-38-N
Elbow adapter Male thread/Female thread Series TH16C; Nickel plated brass; Conical thread; Thread 3/8"
TH38C-38-N-Z
x 1.0
