Tube fittings - Zinc plated steel ISO 8434-1 (DIN 2353)
High pressure banjo Series C-WH-MKDS
Thread Metrical; Elastic seal
Scope of delivery
fitting body, nut, die ring, supplied seperately
Data sheets, CAD files and further documents are available with the respective variant.
