Suitable for Compressors; 3-pin; Protection class IP43; Switching capacity for 3-phase current 5,5kW (400V), At AC 2,5kW (230V); Relief valve, Mechanical ON/OFF-switch; Hysteresis range adjustable; Female thread 1/2"
Pressure switch Series CS -
Digital display, 4 digits; Wetted parts Stainless steel, FKM; 2 Freely adjustable switching outputs; Function NO contact/NC contact; Accuracy 1% of full pressure range; Male thread 1/4“; Power supply 9,6…32VDC; Protection class IP67
Electronic pressure switch Series PS15 -
Change-over contact; Connection Brass; Setting scale; 250VAC/6A; 24VDC/2A; Protection class See Protection cap (Max. IP65)
Vacuum switch Series VS01 -
Other materiales - A06
-
Float PVDF; Female thread Malleable cast iron zinc plated; Scale for air at 6 bar/20°C; Pressure Max. 10bar; Mounting position Vertical pipe; Temperature range +5...+75°C; Application: Air
Flow meter Series FM06/FM07 -
Female thread; Body Nickel plated brass; Temperature Max. +90°C; Application: WaterFlow indicator Series FAA
-
Digital display, 4 digits; Wetted parts Stainless steel 1.4404; 2 Freely adjustable switching outputs (PNP/NPN); Reversible display bar/PSI, Accuracy 0,5% of full pressure range; Window/hysteresis function free programmable; Power supply 15...35VDC; Electric connection M12 (IP67) 4-pin; Pressure range -1...0bar
Electronic pressure switch Series PS17 -
Body Nickel plated brass; Medium temperature Max. 90°C; Application: WaterFlow indicator Series FM26
-
Body, Wetted parts Stainless steel 1.4571; Outlet signal 4...20 mA Proportional to applied pressure; Male thread 1/2"; Accuracy 0,5% of full pressure rangePressure transmitter Series PT08
-
Temperature range -10…+100°C; Pressure Max. 16bar; Application: Water; Pressure drop 0,25Bar
Flow indicator Series FM25 -
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contact
Flow monitors With Inspection glass Series RVO/U -
Connections, Float Stainless steel AISI 316Ti; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series RVO/U
-
Body, Wetted parts Stainless steel 1.4404; Outlet signal 4...20 mA Proportional to applied pressure; Accuracy 0,5% of full pressure rangePressure transmitter Series PT04
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series FM10-N
-
Viscosity compensated ...600mm²/s; Body Nickel plated brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; Application: Monitoring of lubrication
Flow monitors Series FM24 -
Viscosity compensated ...600mm²/s; Body Stainless steel 1.4571; For any mounting position; Medium temperature Max. 120°C; Oil scale; Application: Monitoring of lubricationFlow monitors Series FM24
-
Change-over contact; Connection Brass; Setting scale; 250VAC/6A; 24VDC/2A; Protection class See Protection cap (Max. IP65)
Pressure switch Series PS01 -
Change-over contact; Diaphragm FKM; Setting scale; 250VAC/6A; 24VDC/2A; Male thread 1/4"; Protection class See Protection cap (Max. IP65)
Pressure switch Series PS01 -
Body, Wetted parts Stainless steel 1.4404; Pressure sensor Stainless steel AISI 316L; Seal NBR; Outlet signal 0...10V Proportional to applied pressure; Male thread 1/4"; Accuracy 1% of full pressure rangePressure transmitter Series PT02
-
Viscosity compensated 32...600mm²/s; Body Nickel plated brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact; Application: Monitoring of lubricationFlow monitors Series FM03-N
-
Viscosity compensated 32...600mm²/s; Body Stainless steel AISI 316Ti; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact; Application: Monitoring of lubricationFlow monitors Series FM03-W
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; Change-over contact
Flow monitors With Inspection glass Series RVO/U-MS-W -
Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 120°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contactFlow monitors Series FM02-N
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contactFlow monitors With Inspection glass Series FM42-N
-
Connections, Float Nickel plated brass; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Air scale; Switching range at 1 bar absolute; 20°C; Change-over contactFlow monitors With Inspection glass Series FM42-N
-
Connections, Float Stainless steel AISI 316Ti; Body Aluminum Not wetted; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors With Inspection glass Series FM10-W
-
Brass; Female thread/Male thread
Flow limiter Series BB -
Brass; Female threadFlow limiter Series BA
-
Suitable for Compressors; 3-pin; Protection class IP54; Switching capacity for 3-phase current 7,5kW (400V), At AC 2,2kW (230V); Hysteresis range adjustable; Overpressure protection 35bar; Female thread 1/2"; Motor protection relay; Relief valve; Mechanical ON/OFF-switch
Pressure switch Series MDR3 -
Brass; Male thread
Flow limiter Series BC -
Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contact
Flow monitors Series FM01-N -
Body, Float Stainless steel 1.4571; For any mounting position; Medium temperature Max. 100°C; Water scale; NO contactFlow monitors Series FM01-W
-
Viscosity compensated 32...600mm²/s; Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 120°C; Oil scale; NO contact
Flow monitors Series FM13-N -
Body Nickel plated brass; Float Brass; Vertical mounting; Medium temperature Max. 100°C; Water scale; NO contactFlow monitor with flow indicator Series FM18-N
-
Body Nickel plated brass Float POM; For any mounting position; Medium temperature Max. 80°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contact;Flow monitors Series FM30
