Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA541-112-20L
Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Body 1.4404 Polished, Ball 1.4404; Seals PTFE/FKM; Full bore; Medium temperature 0...+100°C; G 11/2"; DN 40mm; Pressure range 0...40bar; Length 134mm; Operating time 9s; Voltage 24VAC/DC; Ball T; Flow path 02
BA684-RD78X16-D0
Ball valve with pneumatic actuator; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Double acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Connection RD78x1/6"; Nominal diameter 50mm; Pressure range 0...40bar; Length 182mm; Actuator PAD085; Ball L
SQ052A-0B8-Q17
Electrical actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; 2 Torque switches; Incl. manual emergency override; Torque 50-150Nm; Operating time 8s; Voltage 230V/50Hz; Protection class IP68
BA051-50-S0-A-02
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D; Fire-Safe/Antistatik According to ATEX/TA−Luft; Length According to EN558−1 R27; Body, Ball 1.4408; Seals PTFE/Graphoil/FK; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Pressure range 0...40bar; Flange PN40; Length 150mm; Actuator PAS1255; Free of oil and grease for oxygen
8P024600-80
Flanged ball valve with pneumatic actuator; Fire-Safe/Antistatik According to ATEX/TA−Luft; Length According to EN558−1 R27; Body Steel; Ball 1.4301; Seals PTFE/FKM; Double acting actuator; Control pressure 6...8bar; Medium temperature -10...+160°C; Nominal diameter 80mm; Pressure range 0-40bar; Flange PN40; Length 180mm; Actuator PAD100
BA384-100-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Body Steel A352-LCB, Ball 1.4301; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Nominal diameter 100mm; Pressure range 0-16bar; Flange PN16; Length 190mm; Actuator PAS1255
BA079-100-0L
Flanged ball valve with electrical actuator; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE-Graphite/FKM; DN 100mm; Length 152mm; Operating time 27s; Voltage 24V50-60Hz/DC; Steam applications Max. 15bar/198°C
BA045-65-S0
Flanged ball valve with pneumatic actuator; Flange PN40; Body Steel; Ball 1.4301; PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...40bar; Nominal diameter 65mm; Length 103mm; Actuator PAS1605
BA049-40-0Q-A
Flanged ball valve with electrical actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; DN 40mm; Pressure range 0-16bar; Length 63,5mm; Operating time 20s; Voltage 100-240V/50-60Hz; 100-350VDC; Protection class IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb;
BA130-80-S0-01
Ball valve with pneumatic actuator; Flange PN40; For steam; Full bore; Body, Ball 1.4401; Seals PTFE-Graphite/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20…187°C; Nominal diameter 80mm; Length 122mm; Pressure range 0...11bar; Actuator PAS1255
BA130-80-T0-01
Ball valve with pneumatic actuator; Flange PN40; For steam; Full bore; Body, Ball 1.4401; Seals PTFE-Graphite/FKM; Single acting actuator-NO; Control pressure 5,5...8bar; Medium temperature -20…187°C; Nominal diameter 80mm; Length 122mm; Pressure range 0...11bar; Actuator PAS1255
BA179-50-0H
Flanged ball valve with electrical actuator; Fire safe/anitstatic according to ATEX/TA-Luft certification; Flange PN100, Full bore; Body steel A350-LF2, Ball 1.4301; Seals PTFE/FKM/Graphite; Pressure range 0...100bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Length 100mm Operating time 27s; Voltage 100-240VAC
BA049-80-0H-01
Flanged ball valve with electrical actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; DN 80mm; Pressure range 0-16bar; Length 122mm; Operating time 27s; Voltage 100-240VAC; VB190-H
BA774-10-2S0
ball valve with pneumatic actuator; female thread 3-way-type; sealing on two sides; pressure inlet just in front; housing, ball stainless steel; seals POM/EPDM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+100°C; pressure range 0...315bar; G 1"; nominal diameter 25mm; length 66mm; actuator PAS1405; ball T; flow path 02
BA049-80-D0-01
STASTO Combination#br#Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 122mm; Actuator PAD085; Limit switch box EB0X03; 5/2-way solenoid valve - NAMUR type ABS54; 24VDC-LED
BA044-80-0H-01
Flanged ball valve with electrical actuator; Length According to EN558−1 R27; Body Zinc plated steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; DN 80mm; Pressure range 0-16bar; Flange PN16; Length 180mm; Operating time 27s; Voltage 100-240VAC, Actuator VB190 (190Nm) Instead of VB110
BA091-65-CH
Ball valve with electrical actuator; Butt weld ends; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+160°C; DN 65mm; Pressure range 0-16bar; Length 153mm; Operating time 27s; Voltage 100...240VAC; Incl. Positioner 4-20mA/0-10V; Accumulator for safety position Function NC
BA050-80-D0-01
STASTO Combination#br#Flanged ball valve; Flange PN16; Full bore; Body; Ball 1.4401; Seals PTFE-Graphite/FKM; Nominal diameter 80mm; Length 122mm; Steam applications Max. 15bar/198°C; Double acting actuator; Control pressure 5,5...8bar; Actuator PAD100; Limit switch box EB0X03; 5/2-way solenoid valve - NAMUR type ABS54; 24VDC-LED
BA541-112-3PL
ball valve with electrical actuator; 3-way-type; sealing on three ports; housing AISI 316L polished, ball AISI 316L; seals PTFE/FKM; full bore; medium temperature 0...+100°C; G 11/2"; DN 40mm; pressure range 0…64bar; length 134mm; operating time 9s; voltage 24VAC/DC; ball T; including accumulator for safety position; function NC; flow path 03
BA541-112-PL
ball valve with electrical actuator; 3-way-type; sealing on three ports; housing AISI 316L polished, ball AISI 316L; seals PTFE/FKM; full bore; medium temperature 0...+100°C; G 11/2"; DN 40mm; pressure range 0…64bar; length 134mm; operating time 9s; voltage 24VAC/DC; ball T; including accumulator for safety position; function NC
