Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA033-38N-S0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; 3/8"NPT; Nominal diameter 10mm; Pressure range 0…64bar; Length 57mm; Actuator PAS0525
BA152-114-D0-A
Ball valve with pneumatic actuator; Body Brass; Ball Stainless steel AISI 304; Seals PTFE/EPDM/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 11/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 102mm; Actuator PAD032; ATEX-design
BA146-50-D0
Ball valve with pneumatic actuator; Butt weld ends Long; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Pressure range 0-25bar; Length 336mm; Actuator PAD075
BA557-38-S0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4404; Seals PTFE/EPDM Special; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -45...+150°C; Ambient temperature -20...+85°C; 3/8"NPT; Nominal diameter 10mm; Pressure range 0-64bar; Length 52mm; Actuator PAS0525;
BA557-38-T0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4404; Seals PTFE/EPDM Special; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -45...+150°C; Ambient temperature -20...+85°C; 3/8"NPT; Nominal diameter 10mm; Pressure range 0-64bar; Length 52mm; Actuator PAS0525; Safety position NO
BAC1-002-SSCV-S0
Ball valve, carbon-graphite-PTFE seal.52 single-acting, body and ball 1.4401, female/female thread connection RP1/4"
BAC1-003-SSCV-S0
Ball valve, carbon-graphite-PTFE seal.52 single-acting, body and ball 1.4401, female/female thread connection RP3/8"
BA391-34-S0-A-01
ball valve with pneumatic actuator; ATEX II 2 G/D; female thread; housing, ball AISI 316; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1"; nominal diameter 20mm; pressure range 0-64bar; length 78mm; V-ball 30-60°; actuator PAS0525
BA391-34-T0-A-01
ball valve with pneumatic actuator; ATEX II 2 G/D; female thread; housing, ball AISI 316; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 3/4"; nominal diameter 20mm; pressure range 0-64bar; length 78mm; V-ball 30-60°; actuator PAS0525; safety position NO
BA081-10N-D0-A
Ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Double acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -20...+160°C; 1"NPT; Nominal diameter 25mm; Pressure range 0-64bar; Length 90mm; Actuator PAD052
ATSV1205-01
Mounting bridge; Material Zinc plated steel; Flange 1 F12; Flange 2 F05; Height 80mm; With Through-hole 37mm
BA080-34-S2
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -20...+160°C; RP 3/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 76mm; Actuator PAS0633
BES-516-114-SA1-05
Inductive proximity switch; M30x1,5; Voltage 10...30VDC; PNP NO contact/NC contact
BA080-34-T2
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -20...+160°C; RP 3/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 76mm; Actuator PAS0633; Safety position NO
ABS96
Mounted pilot valve; NAMUR; Silencer; Standard coil MA22-ATEX; Connector size 22mm; 3/2-way solenoid valve - NAMUR type (PS128-12-C-01); ATEX EEx m II T4; Actuator PAD330
BA033-12-S0-P1
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator ; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 1/2"; Nominal diameter 15mm; Pressure range 0…64bar; Length 65mm; Actuator PAS0525; Incl. Technical valve passport RU According to TR CU 032/2013; Incl. TR CU 032/2013 (Incl. Strength calculation), TR CU 010/2011; Incl. EAC-Certificate
BA202-34-D0-01
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE coal filled; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+180°C; G 3/4"; Nominal diameter 20mm; Pressure range 0-64bar; Length 72mm; Actuator PAD052
BA033-12-D0-01
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 1/2"; Nominal diameter 15mm; Pressure range 0-64bar; Length 65mm; Actuator PAD052-H; High temperature design
BA080-114-T0
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 11/4"; Nominal diameter 32mm; Pressure range 0-40bar; Length 102mm; Actuator PAS0525; Safety position NO
BA222-TCC34-B
Ball valve; 3-way-type; Sealing on four ports; Full bore; Body, Ball 1.4404; Seals PTFE/FKM; Medium temperature -20...+170°C; Tri-Clamp connection 3/4"; Nominal diameter 15mm; Pressure range 0-100bar; Ball L; Length 118mm; Flange ISO5211 F03; Square 9mm
