STASTO Combination

Name: STASTO Combination
Brand: STASTO
SKU: C0R002
Price: 79.7 EUR
Availability: InStock

STASTO Combination
Fully assembled and tested
Consists of:
Ball valve made of brass Series BAW1; With drain hole; Female thread; Connection G 1/2"; Pressure range 0-14bar; With locking device; T-adapter And Manometer; Diameter 63mm, Display 0...16bar

Intrastat No.: 84818081
Country of origin: Italy
Weight: 0.52 Kg
Short Itemnumber: C0R002

STASTO Combination
fully assembled and tested
consists of:
ball valve made of brass series BAW1; with drain hole; female thread; connection G 1/2"; pressure range 0-14bar; with locking device; T-adapter and manometer; diameter 63mm, display 0...16bar

79,70 € 79.7 EUR 79,70 €

Connection
- -
Dimension
- -
Function
- -
Max. inlet pressure
- -
Flow at 6bar/Δp=1bar
- -
Filter element
- -

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

No Specifications

BAW1-004-BLTT-MZL x 1.0

Ball valve made of brass BAW1-004-BLTT-MZL

Ball valve made of brass Series BAW1; With drain hole; Female thread; Seal PTFE; Medium temperature -10...+100°C; Hand lever Steel; Pressure range 0...14bar; With locking device; RP 1/2"; Nominal diameter 15mm; Length 59mm

Add to Cart

TH60-14-12-N x 1.0

Female to male reducer adapter TH60-14-12-N

Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 1/2"

Add to Cart

TH24C-12-N x 1.0

T-adapter Female thread/Female thread/Male thread 1/2"

T-adapter Female thread/Female thread/Male thread Series TH24C; Nickel plated brass; Conical thread; Thread 1/2"

Add to Cart

MA001-63B-16 x 1.0

Bourdon tube manometer MA001-63B-16

Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Below; Class 1,6; Diameter 63mm; Indicating range 0-16; Unit bar; Connection 1/4"

Add to Cart
