BUWC-700-DSE-G

Butterfly valve with bare shaft Series BUW1-DSE-B, BUW2-DSE-B, BUW6-DSE-B, BUWC-DSE-B, BUWV-DSE-B, BUWZ-DSE-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 700mm; Length 165mm; Pressure range 0…10bar; Flange PN10

Gear box; Body Cast iron; Protection class IP67; ATEX Area 1/21; Torque 5500Nm; Flange ISO5211 F25; Diameter/Key 70/20mm

Hexagon head screw Series SW002-I; 1.4301; According to ISO4017; Thread M16X45

Spring washer Series SWA004-I; 1.4301; According to DIN127; Thread M16
