BUW9-200-CSIQ-G-3C

Butterfly valve with bare shaft Series BUW9-CSIQ-B; Wafer type; Double eccentric; Length According to EN558−1R20; Body Carbon steel A216-WCB Epoxy coated; Disc 1.4408; Shaft 1.4542; Seat Inconel 625; Medium temperature -10...+425°C; Pressure range 0...25bar; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; DN 200mm; Length 61mm; Nominal flange pressure PN10/16/25/ANSI150

Gear box; Body Cast iron; Protection class IP67; ATEX Area 1/21; Torque 1000Nm; Flange ISO5211 F10; Female square 22mm

Hexagon head screw Series SW002-I; 1.4301; According to ISO4017; Thread M10X16

Spring washer Series SWA004-I; 1.4301; According to DIN127; Thread M10
