Butterfly valve with pneumatic actuator BUW6-125-DSE-D22-01-ABS55-PI16-06-14-N-0-360-C001-03-C002-31-6-EB0X01

Name: Butterfly valve with pneumatic actuator BUW6-125-DSE-D22-01-ABS55-PI16-06-14-N-0-360-C001-03-C002-31-6-EB0X01
SKU: BUW6-125-DSE-D22-01-ABS55-PI16-06-14-N-0-360-C001-03-C002-31-6-EB0X01

BUW6-125-DSE-D22-01
Butterfly valve with pneumatic actuator Series BUW6-DSE-D2; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM; Special grease; Nominal flange pressure PN10/16/ANSI150; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+130°C; Pressure range 0...10bar; DN 125mm; Length 56mm; Actuator PAD085
ABS55
Mounted pilot valve Series ABS; Speed control; Suitable for Pneumatically operated butterfly valve; Standard coil C001; Connector size 22mm; 5/2-Wege-NAMUR-Impulsmagnetventil (NM52W2S-TP); Actuator PAD/PAS052-270
PI16-06-14-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 6mm; Thread 1/4"
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC
EB0X01
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831613; Contact material Silver-nickel; Material of case Plastic

Intrastat No.: 84818085
Country of origin: Italy

Weight: 5.038 Kg
Short Itemnumber: BUW6125DSED2201ABS55PI160614N0360C00103C002316EB0X01

BUW6-125-DSE-D22-01
butterfly valve with pneumatic actuator series BUW6-DSE-D2; wafer type; length according to EN558−1R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner EPDM; Special grease; nominal flange pressure PN10/16/ANSI150; double acting actuator; control pressure 5,5...8bar; medium temperature -10...+130°C; pressure range 0...10bar; DN 125mm; length 56mm; actuator PAD085
ABS55
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-Wege-NAMUR-Impulsmagnetventil (NM52W2S-TP); actuator PAD/PAS052-270
PI16-06-14-N-0-360
swivel male elbow series PI16-360; nickel plated brass; cylindrical thread; diameter 6mm; thread 1/4"
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic

On request

This combination does not exist.

Availability:

See availability

Technical specifications

Pressure range	0...10 bar
DN	125 mm
Length	56 mm
Voltage	24VDC / 48V/50-60Hz

All specifications (10)

Documents

Data sheets, drawings and CAD files

Pressure range	0...10 bar
DN	125 mm
Length	56 mm
Voltage	24VDC / 48V/50-60Hz
Design	Standard
Diameter	6 mm
Male thread	G 1/4"
Switch type	Crouzet 831613
Contact material	Silver-nickel
Material of case	Plastic
