BULU-250-CSN-G-3C

Butterfly valve with bare shaft Series BUL1-CSN-B, BULA-CSN-B, BULG-CSN-B, BULC-CSN-B, BULY-CSN-B; Lug type; Length According to EN558−1R20; Body Steel Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -10...+100°C; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness; DN 250mm; Length 68mm; Pressure range 0…10bar; Flange ANSI150

Gear box; Body Cast iron; Protection class IP67; ATEX Area 1/21; Torque 1000Nm; Flange ISO5211 F10; Female square 22mm

Hexagon head screw Series SW002-I; 1.4301; According to ISO4017; Thread M10X30

Spring washer Series SWA004-I; 1.4301; According to DIN127; Thread M10
