BDH5-100-T-001-ABS54-C001-03-C002-31-6

BDH5-100-T-001-ABS54-C001-03-C002-31-6

BDH5-100-T-001
Ring-butterfly damper with pneumatic actuator, Single acting, DN100, PN10; Body, Disc And Shaft 1.4841; High temperature-Packing gland Body seat ring; Mounting bracket Both sides Zinc plated steel; Height 300mm And 200mm; Temperature range Max. 1000°C; Operating pressure Max. 500mbar, Length 52mm; Control pressure 5,5...8bar; Rotation angle: 0...90° Adjustable, PAS1255-R; Wafer; Leakage rate App. 0,5%; Safety position NO
ABS54
Mounted pilot valve Series ABS; Speed control; Suitable for Pneumatically operated butterfly valve; Standard coil C001; Connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); Actuator PAD/PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818085
Country of origin: Germany
Weight: 29.64 Kg
Short Itemnumber: BDH5100T001ABS54C00103C002316

BDH5-100-T-001
ring-butterfly damper with pneumatic actuator, single acting, DN100, PN10; body, disc and shaft AISI 314; high temperature-packing gland body seat ring; mounting bracket both sides zinc plated steel; height 300mm and 200mm; temperature range max. 1000°C; operating pressure max. 500mbar, length 52mm; control pressure 5,5...8bar; rotation angle : 0...90° adjustable, PAS1255-R; wafer; leakage rate app. 0,5%; safety position NO
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
