  5. Flanged ball valve with pneumatic actuator Series BAEB, BAEA
  6. BAEB-015-SSTV-S0-ABS54-C001-03-C002-31-6
BAEB-015-SSTV-S0-ABS54-C001-03-C002-31-6

BAEB-015-SSTV-S0-ABS54-C001-03-C002-31-6

BAEB-015-SSTV-S0
flanged ball valve with pneumatic actuator series BAEB, BAEA; fire-safe; TA-Luft; length according to EN558−1R27; body, ball AISI 316; seals PTFE/Graphoil/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 15mm; pressure range 0-40bar; flange PN40; length 115mm; actuator PAS0525
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 4.5 Kg
Short Itemnumber: BAEB015SSTVS0ABS54C00103C002316
https://www.stasto.eu/web/image/product.template/233508/image_1920?unique=d9024cc

BAEB-015-SSTV-S0
flanged ball valve with pneumatic actuator series BAEB, BAEA; fire-safe; TA-Luft; length according to EN558−1R27; body, ball AISI 316; seals PTFE/Graphoil/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 15mm; pressure range 0-40bar; flange PN40; length 115mm; actuator PAS0525
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

820,80 € 820.8 EUR 820,80 €

price on request

  • Valve interface Namur
  • DN
  • Length
  • Flange
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Coil
  • Actuator
  • Actuator 2

This combination does not exist.

Availability:
Contact Us

Share

dimension
Valve interface Namur 1/4"
DN 15 mm
Length 115 mm
Flange PN40
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...40 bar
characteristics
Coil C001
Actuator PAS0525
Actuator 2 PAS
