Ball valve with pneumatic actuator Series BAC5 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Ball valves - pneumatically operated
  5. Ball valve with pneumatic actuator Series BAC5
  6. BAC5-004-SSTV-S0-ABS53-C001-03-C002-31-6
BAC5-004-SSTV-S0-ABS53-C001-03-C002-31-6
Ball valve with pneumatic actuator BAC5-004-SSTV-S0
Ball valve with pneumatic actuator BAC5-004-SSTV-S0
360,30 €
360,30 €
BAC5-004-SSTV-S0-ABS53-C001-03-C002-31-LV-2
BAC5-004-SSTV-S0-ABS53-C001-03-C002-31-LV-2
504,82 €
504,82 €

BAC5-004-SSTV-S0-ABS53-C001-03-C002-31-6

BAC5-004-SSTV-S0
Ball valve with pneumatic actuator Series BAC5; Socket weld ends; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 15mm; Pressure range 0-64bar; Length 65mm; Actuator PAS0525
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 2.143 Kg
Short Itemnumber:BAC5004SSTVS0ABS53C00103C002316
https://www.stasto.eu/web/image/product.template/198011/image_1920?unique=fd46ad6

BAC5-004-SSTV-S0
ball valve with pneumatic actuator series BAC5; socket weld ends; body, ball AISI 316; seals PTFE-reinforced/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 15mm; pressure range 0-64bar; length 65mm; actuator PAS0525
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

499,79 € 499.79 EUR 499,79 €

price on request

  • Socket weld ends
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Coil
  • Actuator

This combination does not exist.

Availability:
Contact Us
dimension
Socket weld ends 15 mm
Valve interface Namur 1/4"
DN 15 mm
Length 65 mm
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...64 bar
characteristics
Coil C001
Actuator PAS0525

Data sheets, Instructions, 3D-files and Certificates...
