Ball valve with pneumatic actuator Series BAC1 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Ball valves - pneumatically operated
  5. Ball valve with pneumatic actuator Series BAC1
  6. BAC1-010-CITV-D0-ABS51-C001-03-C002-31-6
BAC1-010-CITV-D0-ABS51-C001-03-C002-31-6
Ball valve with pneumatic actuator BAC1-010-CITV-D0
Ball valve with pneumatic actuator BAC1-010-CITV-D0
925,91 €
925,91 €
BAC1-010-CITV-D0-ABS51-C001-03-C002-31-LV-2
BAC1-010-CITV-D0-ABS51-C001-03-C002-31-LV-2
1.077,25 €
1.077,25 €

BAC1-010-CITV-D0-ABS51-C001-03-C002-31-6

BAC1-010-CITV-D0
Ball valve with pneumatic actuator Series BAC1; Female thread; Body Steel; Ball 1.4301; Seals PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+160°C; RP 21/2"; Nominal diameter 65mm; Pressure range 0-16bar; Length 153mm; Actuator PAD085
ABS51
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); Actuator PAD052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 13.05 Kg
Short Itemnumber:BAC1010CITVD0ABS51C00103C002316
