  5. Ball valve with pneumatic actuator Series BAC1
  6. BAC1-006-SSTV-D0-ABS51-C001-03-C002-31-6-EB0X03-FR01-14-0,5/8
BAC1-006-SSTV-D0-ABS51-C001-03-C002-31-6-EB0X03-FR01-14-0,5/8

BAC1-006-SSTV-D0-ABS51-C001-03-C002-31-6-EB0X03-FR01-14-0,5/8

BAC1-006-SSTV-D0
ball valve with pneumatic actuator series BAC1; female thread; body, ball AISI 316; seals PTFE/FKM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1"; nominal diameter 25mm; pressure range 0-40bar; length 92mm; actuator PAD052
ABS51
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X03
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/230VAC-1A/24VDC; switch type Crouzet 83.161.301; contact material silver-nickel; material of case plastic; cover aluminum
FR01-14-0,5/8
filter regulator series FR01/FR; relieving; drain valve semi-automatic; pressure range 0,5...8bar; filter element 20µm; plastic bowl with protection cage; connection 1/4"; flow at 6,3bar/Δp=1bar 1200Nl/min; max. inlet pressure 16bar

Intrastat No.: 84818081
Country of origin: Italy
Weight: 3.948 Kg
Short Itemnumber: BAC1006SSTVD0ABS51C00103C002316EB0X03FR01140.58
https://www.stasto.eu/web/image/product.template/219032/image_1920?unique=94b97ec

BAC1-006-SSTV-D0
ball valve with pneumatic actuator series BAC1; female thread; body, ball AISI 316; seals PTFE/FKM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1"; nominal diameter 25mm; pressure range 0-40bar; length 92mm; actuator PAD052
ABS51
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X03
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/230VAC-1A/24VDC; switch type Crouzet 83.161.301; contact material silver-nickel; material of case plastic; cover aluminum
FR01-14-0,5/8
filter regulator series FR01/FR; relieving; drain valve semi-automatic; pressure range 0,5...8bar; filter element 20µm; plastic bowl with protection cage; connection 1/4"; flow at 6,3bar/Δp=1bar 1200Nl/min; max. inlet pressure 16bar

816,80 € 816.8 EUR 816,80 €

price on request

  • Diameter
  • Connection
  • Male thread
  • Attachment interface VDI/VDE 3845
  • Attachment interface 2 VDI/VDE 3845
  • Valve interface Namur
  • Female thread
  • DN
  • Length
  • Function
  • Connector size
  • Switch type
  • Design
  • Voltage
  • Switching capacity
  • Pressure range
  • Contact material
  • Material of case
  • Coil
  • Actuator
  • Actuator 2
  • Max. inlet pressure
  • Filter element
  • Flow rate at 6.3bar/Δp=1bar

This combination does not exist.

Availability:
Contact Us

Share

dimension
Connection 1/4"
Valve interface Namur 1/4"
Female thread RP 1"
DN 25 mm
Length 92 mm
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...40 bar
characteristics
Coil C001
Actuator PAD052
Max. inlet pressure 16 bar
Filter element 20 µm
Flow rate at 6.3bar/Δp=1bar 1200 Nl/min
