Ball valve with pneumatic actuator Series BA091-D0B/D01 Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Other materiales - A03
  5. Ball valve with pneumatic actuator Series BA091-D0B/D01
  6. BA091-25-D0-03-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360
BA091-25-D0-03-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360

BA091-25-D0-03-ABS54-C001-03-C002-31-6-PI16-08-14-N-0-360

BA091-25-D0-03
Ball valve with pneumatic rotary actuator Series BA091-D0B/D01; Weld-on ends; Housing, Ball 1.4401; Seals PTFE-reinforced/FKM; Double-acting actuator, oversized; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Nominal diameter 25mm; Print area Steam 0...15bar; Installation length 92mm; Drive PAD063
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
PI16-08-14-N-0-360
swivel male elbow series PI16-360; nickel plated brass; cylindrical thread; diameter 8mm; thread 1/4"

Intrastat No.: 84818081
Country of origin: Italy
Weight: 3.69 Kg
Short Itemnumber: BA09125D003ABS54C00103C002316PI160814N0360
https://www.stasto.eu/web/image/product.template/221063/image_1920?unique=3970b0b

BA091-25-D0-03
Ball valve with pneumatic rotary actuator Series BA091-D0B/D01; Weld-on ends; Housing, Ball 1.4401; Seals PTFE-reinforced/FKM; Double-acting actuator, oversized; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Nominal diameter 25mm; Print area Steam 0...15bar; Installation length 92mm; Drive PAD063
ABS54
mounted pilot valve series ABS; speed control; suitable for pneumatically operated butterfly valve; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD/PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
PI16-08-14-N-0-360
swivel male elbow series PI16-360; nickel plated brass; cylindrical thread; diameter 8mm; thread 1/4"

655,80 € 655.8 EUR 655,80 €

price on request

  • Diameter
  • Male thread
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Pressure range Steam
  • Coil
  • Actuator
  • Actuator 2

This combination does not exist.

Availability:
Contact Us

Share

dimension
Diameter 8 mm
Male thread G 1/4"
Valve interface Namur 1/4"
DN 25 mm
Length 92 mm
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...40 bar
Pressure range Steam 0...15 bar
characteristics
Coil C001
Actuator PAD063
Actuator 2 PAS
