BA077-50-S0-01

BA077-50-S0-01

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE-Fibre-glass-reinforced/EPDM; Compensation hole; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -35...+140°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator Low temperature design PAS1005-L

Intrastat No.: 84818081
Country of origin: Italy
Weight: 14.26 Kg
Short Itemnumber: BA07750S001
https://www.stasto.eu/web/image/product.template/127222/image_1920?unique=f96ddcc

flanged ball valve with pneumatic actuator; flange PN16; body, ball AISI 316; seals PTFE-fibre-glass-reinforced/EPDM; compensation hole; single acting actuator; control pressure 5,5...8bar; medium temperature -35...+140°C; pressure range 0...16bar; nominal diameter 50mm; length 82mm; actuator low temperature design PAS1005-L

999.999,00 € 999999.0 EUR 999.999,00 €

On request

  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range 0...16bar
Brand STASTO
Pressure range 0...16bar
Brand STASTO
720807-50 x 1.0 Pcs
720807-50
Flanged ball valve; Flange PN16, Full bore; Body; Ball 1.4401; Seals PTFE-Fibre-glass-reinforced/EPDM; Pressure range 0...16bar; Medium temperature -35...+140°C; Nominal diameter 50mm; Length 82mm; Compensation hole
Pneumatic actuator PAS1005-L
PAS1005-L x 1.0 Pcs
Pneumatic actuator PAS1005-L
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Seals Silicone; Temperature range -40...+85°C; Diameter 100mm; Flange ISO5211 F07/F10; Female square 17mm; Torque at 5,5bar 42,3Nm
RI3009 x 1.0 Pcs
RI3009
Mounting bracket; F07/F05-F05; Bolt 17-10
