Flanged ball valve with pneumatic actuator Series BA045-S Store

Flanged ball valve with pneumatic actuator BA045-15-S0

Name: Flanged ball valve with pneumatic actuator BA045-15-S0
Brand: STASTO
SKU: BA045-15-S0
Price: 464.1 EUR
Availability: InStock

Flanged ball valve with pneumatic actuator Series BA045-S0; Flange PN40; Body Steel; Ball 1.4301; PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...40bar; Nominal diameter 15mm; Length 35mm; Actuator PAS0635

Intrastat No.: 84818081
Country of origin: Italy
Weight: 3.59 Kg
Short Itemnumber: BA04515S0

flanged ball valve with pneumatic actuator series BA045-S0; flange PN40; body steel; ball AISI 304; PTFE-reinforced/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...40bar; nominal diameter 15mm; length 35mm; actuator PAS0635

464,10 € 464.1 EUR 464,10 €

Valve interface Namur
- -
DN
- 15 mm
Length
- 35 mm
Connector size
- -
Design
- -
Voltage
- -
Pressure range
- -
Coil
- -
Actuator
- PAS0635

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

dimension
DN	15 mm
Length	35 mm
characteristics
Actuator	PAS0635

720008-15 x 1.0

Flanged ball valve 720008-15

Flanged ball valve Series 720008; Flange PN40, Full bore; Body Steel; Ball 1.4301; Seals PTFE-reinforced/FKM; Pressure range 0...40bar; Medium temperature -20...+160°C; Nominal diameter 15mm; Length 35mm

Add to Cart

PAS0635 x 1.0

Pneumatic actuator PAS0635

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 63mm; Flange ISO5211 F05/F07; Female square 14mm; Torque at 5,5bar 10,6Nm

Add to Cart

RI3780 x 1.0
