BA043-50-S2

Name: BA043-50-S2
Brand: STASTO
SKU: BA043-50-S2
Price: 999.0 EUR
Availability: InStock

Flanged ball valve with pneumatic actuator; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -10...+160°C; Pressure range 0...16bar; Nominal diameter 50mm; Length 82mm; Actuator PAS1153

Intrastat No.: 84818081
Country of origin: Italy
Weight: 20.85 Kg
Short Itemnumber: BA04350S2

flanged ball valve with pneumatic actuator; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 4...8bar; medium temperature -10...+160°C; pressure range 0...16bar; nominal diameter 50mm; length 82mm; actuator PAS1153

999,00 € 999.0 EUR 999,00 €

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

No Specifications

722000-50 x 1.0

Flanged ball valve 722000-50

Flanged ball valve Series 722000; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Length 82mm

Add to Cart

PAS1153 x 1.0

Pneumatic actuator PAS1153

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 115mm; Flange ISO5211 F07/F10; Female square 22mm; Torque at 5,5bar 60,8Nm

Add to Cart

RI3009 x 1.0
