STASTO Allgemeine Preisliste (EUR)
BA043-32-S0-3C

BA043-32-S0-3C

Flanged ball valve with pneumatic actuator Series BA043; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855; Incl. Inspection certificate EN-10204-3.1 For material, pressure, function and tightness

Intrastat No.: 84818081
Country of origin: Italy
Weight: 8.31 Kg
Short Itemnumber: BA04332S03C
https://www.stasto.eu/web/image/product.template/240281/image_1920?unique=d975ddd

Flanged ball valve with pneumatic actuator Series BADA; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855

660,90 € 660.9 EUR 660,90 €

Not Available For Sale

excl. tax
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range 0...16bar
Brand STASTO
Pressure range 0...16bar
Brand STASTO
Flanged ball valve BA043-32-L-3C
BA043-32-L-3C x 1.0 Pcs
Flanged ball valve BA043-32-L-3C
Flanged ball valve Series BA043-L-3C; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Incl. Inspection certificate EN-10204-3.1 For material, pressure, function and tightness; Nominal diameter 32mm; Length 54mm
Pneumatic actuator PAS0855
PAS0855 x 1.0 Pcs
Pneumatic actuator PAS0855
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 85mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 28,7Nm
RI3048 x 1.0 Pcs
RI3048
Mounting bracket; F05-F04/03; Bolt 14-8
