STASTO Combination
Fully assembled and tested
Solenoid valve unit 3-fold Consists of:
3 x 5/2-way valve; E52W2S014; Connection 1/4"
Voltage 2230VAC; Electrical/electrical
Incl. Silencer Into The Base plate
STASTO Combination
fully assembled and tested
solenoid valve unit 3-fold consists of:
3 x 5/2-way valve; E52W2S014; connection 1/4"
voltage 2230VAC; electrical/electrical
incl. silencer into the base plate
Technical specifications
| Brand | STASTO |
|---|
| Brand | STASTO |
ME314
x 1.0 Pcs
Manifold sub-base Series ME; For way-valves Series E5 And V5; Anodized aluminum; Number of valves 3; Pressure connection 3/8"; Exhaust ports 3/8"; Valve size 1/4"
E52W2S014
x 3.0 Pcs
5/2-way valve E52W2S014
5/2-way valve Series E5.; Pilot-operated; Pressure range 1,5...10bar; Actuation Electrical/electrical; Standard coil C001; Connector size 22mm; Connection 1/4"; Nominal diameter 8mm; Flow rate 1080Nl/min
C002-31-6
x 6.0 Pcs
Connector C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC
SLN-M38-RB
x 2.0 Pcs
Silencer SLN-M38-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 3/8"; Length 36mm
TH50-38-N-0
x 1.0 Pcs
Plug screw TH50-38-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 3/8"
