AGG010

STASTO AutomationPackage
Completely picked and checked
Consists of:
4 x TH38C-12-B-Z; Detachable hex nipple;
4 x 110MS-1/2" Needle valve;
4 x TH38C-12-N; Hex nipple;
4 x 21HT4K0Y160-GDV; Solenoid valve;
4 x HN38-13-12-B-C; Male hose nozzle;
2 x RAP6-535; Tube clamp;
4 x GDV14110AY; Coil


Weight:
7.5 Kg
Short Itemnumber:
AGG010
https://www.stasto.eu/web/image/product.template/241155/image_1920?unique=77c101b

STASTO AutomationPackage
completely picked and checked
consists of:
1 x 1810-1/2"; ball valve;
1 x 21HT4K0Y160; solenoid valve;
1 x BDA08223DS; coil;
1 x C003-32-6; connector;
2 x HN38-13-12-B-C; hose nozzle;
2 x 158D; hose clip;
1 x MV230012; check valve

963,60 € 963.6 EUR 963,60 €

Not Available For Sale

excl. tax
  • Function
  • Design
  • Actuator
  • Brand

This combination does not exist.

Availability:
See availability

Technical specifications

Brand STASTO
Brand STASTO
110MS-1/2" x 4.0 Pcs
Needle valve 110MS-1/2"
Needle valve Series 110Ms; Body Brass; Stem seal PTFE; Medium temperature -20...+100°C; G 1/2"; DN 6,5mm; Pressure range 0-100bar; Length 55mm; Material handwheel Polyamid
TH38C-12-N x 4.0 Pcs
Hex nipple TH38C-12-N
Hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/2"
21HT4K0Y160-GDV x 4.0 Pcs
2/2-way solenoid valve 21HT4K0Y160-GDV
2/2-way solenoid valve Series 21H..K0Y; Combined operated; NC; Body Brass; Stainless steel tube; Seal NBR; Medium temperature -10...+90°C; Connector size 32mm; G 1/2"; DN 16mm; Pressure AC 0-14bar; Pressure DC 0-14bar; Length 70mm; Standard coil GDV
RAP6-535 x 2.0 Pcs
Tube clamp RAP6-535
Tube clamp Series RAP6; Standard series; Weld-on plate Long; Clamps Polypropylen; Screws, End plate Zinc plated steel, Weld-on plate Steel; Clamp size 5; Diameter Tube Outside 35mm
GDV14110AY x 4.0 Pcs
GDV14110AY
Coil Type GDV/GDH; For higher pressures/temperatures; Connector size 32mm; Voltage 110V/50Hz,120V/60Hz; Approval CSA/UL/VDE
