Knife gate valve with double acting actuator Series A1N2H2-5-PMB Store
  1. Products
  2. Armatures
  3. Valves, butterfly valves and gate valves - automatically operated
  4. Other materiales - A05
  5. Knife gate valve with double acting actuator Series A1N2H2-5-PMB
  6. A1N2H2-5-300-PM-B-ABS42-C001-22-C002-31-6-MSU01A/2
A1N2H2-5-300-PM-B-ABS42-C001-22-C002-31-6-MSU01A/2

A1N2H2-5-300-PM-B-ABS42-C001-22-C002-31-6-MSU01A/2

A1N2H2-5-300-PM-B
knife gate valve with double acting actuator series A1N2H2-5-PMB; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7; gate AISI 304; soft sealed EPDM; packing PTFE-synthetic/EPDM; screws stainless steel; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+90°C; prepared for 2 mechanical switches MSU01A; DN 300mm; length 70mm; pressure range 0…6bar
ABS42
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; standard coil C001; connector size 22mm; 5/2-Wege-Magnetventil (E52W1SM14); DN gate valve 50-400mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
MSU01A/2
electrical position indication series MSU; Suitable for knife gate valves; Built-on mechanical limit switch (2 pieces)

Intrastat No.: 84818061
Country of origin: Spain
Weight: 9.284 Kg
Short Itemnumber: A1N2H25300PMBABS42C00122C002316MSU01A2
https://www.stasto.eu/web/image/product.template/232277/image_1920?unique=f7e7f54

A1N2H2-5-300-PM-B
knife gate valve with double acting actuator series A1N2H2-5-PMB; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7; gate AISI 304; soft sealed EPDM; packing PTFE-synthetic/EPDM; screws stainless steel; nominal flange pressure PN10; unidirectional sealed; control pressure 5,5...8bar; medium temperature -5...+90°C; prepared for 2 mechanical switches MSU01A; DN 300mm; length 70mm; pressure range 0…6bar
ABS42
mounted pilot valve series ABS; suitable for pneumatically operated knife gate valves; 5/2-way solenoid valve; flow control valves; silencer; mounted at cylinder; standard coil C001; connector size 22mm; 5/2-Wege-Magnetventil (E52W1SM14); DN gate valve 50-400mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
MSU01A/2
electrical position indication series MSU; Suitable for knife gate valves; Built-on mechanical limit switch (2 pieces)

2.563,00 € 2563.0 EUR 2.563,00 €
