Knife gate valve without actuator Series A1ED; Wafer type; Body Cast iron EN-GJL-250/Ductile iron EN-GJS-500-7 High temperature-Coating; Gate 1.4401 Mirror polished; Soft sealed FKM; Packing PTFE-Synthetic; Screws Stainless steel; Sliding guide PTFE; Nominal flange pressure PN10; Unidirectional sealed; Medium temperature -5...+200°C; DN 150mm; Length 60mm; Pressure range 0-10bar; 5 Flushing holes in the housing; Reinforced fixing ring Stainless steel; Abrasion protection Stainless steel; Packing gland cap Stainless steel
Country of origin: Spain
Short Itemnumber: A1MD2HS3B150B01
Knife gate valve without actuator series A1ED; wafer type; body cast iron EN-GJL-250/ductile iron EN-GJS-500-7 high temperature-coating; gate AISI 316 mirror polished; soft sealed FKM; packing PTFE-synthetic; screws stainless steel; sliding guide PTFE; nominal flange pressure PN10; unidirectional sealed; medium temperature -5...+200°C; DN 150mm; length 60mm; pressure range 0-10bar; 5 flushing holes in the housing; reinforced fixing ring stainless steel; abrasion protection stainless steel; packing gland cap stainless steel
Technical specifications
| Pressure range | 0...10 bar |
|---|---|
| DN | 125 mm |
| Length | 50 mm |
| Brand | STASTO |
| Pressure range | 0...10 bar |
| DN | 125 mm |
| Length | 50 mm |
| Brand | STASTO |
A1MD2HS3-B-150-B-01
