Valves, butterfly valves and gate valves - manually operated

STASTO Allgemeine Preisliste (EUR)
BULY-150-DSN-L-01
butterfly valve with hand lever series BUL-DSN-L-01; lug type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 150mm; length 56mm; pressure range 0-16bar; nominal flange pressure ANSI150; flange thread UNC
BULY-150-DSN-L-3C01
butterfly valve with hand lever series BUL-DSN-L-3C01; lug type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner NBR; medium temperature -10...+100°C; DN 150mm; length 56mm; pressure range 0-16bar; nominal flange pressure ANSI150; flange thread UNC; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
C3J-GL123-25
inspection certificate EN-10204-3.1; for material, pressure and tightness
C3J-CH009-20
Inspection certificate EN-10204-3.1; For material, pressure and tightness
RIG0112
liner + packing for butterfly valve BUW4-80-DSTS (BVTT/BLTT); PTFE
BDH3-150-B-002
ring-butterfly damper DN150, PN6; body ductile iron EN-JS1030 disc and shaft AISI 304; packing gland adjustable graphite sealing cord; temperature range max. 450°C; operating pressure max. 300mbar; mounting flange ISO F05/F07; square 9mm; with body seat ring
L1P2HS2-2-200-B
knife gate valve series L, DN200, PN10, with hand lever, seat
EPDM; packing cotton greased, body cast iron EN-GJL-250, spool
AISI 316; design fish-friendly; Flow through on both sides; Stainless steel screws
C3J-BULG-100-DNE
Inspection certificate EN-10204-3.1; For material, pressure and tightness
BULG-100-DNE-L-3C
butterfly valve with hand lever series BULG-DNE-L-3C; lug type; length according to EN558−1 R20; body ductile iron EN-GJS-400-15 epoxy coated; disc aluminium-bronze; shaft AISI 430; liner EPDM; medium temperature -10...+130°C; DN 100mm; length 52mm; pressure range 0-16bar; nominal flange pressure PN10/16; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
C3J-BULG-100-DNE-01
inspection certificate EN-10204-3.1; for material, pressure and tightness
BULG-100-DNE-L-3C01
Butterfly valve with hand lever Series BULG-L-3C01; Lug type; Length According to EN558−1 R20; Body Ductile iron EN-GJS-400-15 Epoxy coated RAL5009 C5-High According to EN-ISO 12944; Disc Aluminium-bronze; Shaft 1.4016; Liner EPDM; Medium temperature -10...+130°C; DN 100mm; Length 52mm; Pressure range 0-16bar; Nominal flange pressure PN10/16; Stainless steel nameplate; Stainless steel screws; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
C3J-BULG-100-BNES
inspection certificate EN-10204-3.1; for material, pressure and tightness
BULG-100-BNES-X-3C
butterfly valve with hand lever series BULG-BNES-X-3C; lug type; length according to EN558−1 R20; body aluminium-bronze; disc aluminium-bronze; shaft AISI 316; liner EPDM; medium temperature -10...+130°C; DN 100mm; length 52mm; pressure range 0-16bar; nominal flange pressure PN10/16; hand lever stainless steel; incl. inspection certificate EN-10204-3.1; for material, pressure and tightness
PS-AB1N2H2-5-80
packing; suitable for knife gate valve series AB; DN 80mm; material synthetic PTFE/EPDM
PS-AB1N2H2-5-100
packing; suitable for knife gate valve series AB; DN 100mm; material synthetic PTFE/EPDM
PS-AB1N2H2-5-150
packing; suitable for knife gate valve series AB; DN 150mm; material synthetic PTFE/EPDM
PS-AB1N2H2-5-200
packing; suitable for knife gate valve series AB; DN 200mm; material synthetic PTFE/EPDM
SS-AB1N2H2-5-80
seat seal for AB1N2H2-5-80; EPDM
SS-AB1N2H2-5-100
seat seal for AB1N2H2-5-100; EPDM
SS-AB1N2H2-5-200
seat seal for AB1N2H2-5-200; EPDM
