Other materiales - A03
Store
Category
Filter Search
Guide
Sort By: Featured

Other materiales - A03

STASTO Allgemeine Preisliste (EUR)
BA280-10-QN-A0
ball valve with electrical actuator ATEX II 2 G/D; female thread; body, ball AISI 316; seals PTFE/EPDM; medium temperature -20...+160°C; RP 1"; DN 25mm; pressure range 0-40bar; length 92mm; operating time 15s; voltage 15-30V/50-60Hz; 12-48VDC; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; safety position NO
BA074-25-S0-ABS53-C001-03-C002-31-6
BA074-25-S0
flanged ball valve with pneumatic actuator; flange acc. to ANSI 150; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -10...+160°C; pressure range 0...20bar; nominal diameter 25mm; length 46mm; actuator PAS0635
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
BA074-20-S0-ABS53-C001-03-C002-31-6
BA074-20-S0
flanged ball valve with pneumatic actuator; flange acc. to ANSI 150; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -10...+160°C; pressure range 0...20bar; nominal diameter 20mm; length 40mm; actuator PAS0635
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
BA074-32-S0-ABS53-C001-03-C002-31-6-EB0X01-WSTHVB
BA074-32-S0
flanged ball valve with pneumatic actuator; flange acc. to ANSI 150; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -10...+160°C; pressure range 0...20bar; nominal diameter 32mm; length 54mm; actuator PAS0885
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01-WSTHVB
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic; mounting bridge stainless steel
BA048-50-S0-3C
flanged ball valve with pneumatic actuator series BA048-S-3C; flange PN16; body, ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 50mm; length 82mm; actuator PAS1005; incl. inspection certificate EN-10204-3.1; for material, pressure, function and tightness
BA869-12-CG-01
ball valve with electrical actuator; with control ball V 60°; female thread; body, ball AISI 316; seals PTFE/MFQ; medium temperature -50...+160°C; RP 1/2"; DN 15mm; pressure range 0...140bar; length 66mm; operating time 8s; voltage 24VDC; with integrated positioner 4-20mA/0-10V; compensation hole at the inlet; ambient temperature: -50...+85°C
BA326-50-CL
flanged ball valve with electrical actuator; fire-safe; TA-Luft; length according to EN558−1 R27; full bore; body, ball AISI 316; seals PTFE/MFQ; medium temperature -40...+200°C; nominal diameter 50mm; pressure range 0-40bar; flange PN40; length 150mm; operating time 27s; voltage 24VAC/DC; control signal 4...20mA/0...10V
VB030M-PF8-Q11
electrical actuator; metal; suitable for valves with 90° operation; for a maximum of 100 operations a day; limit switch-off is wired; 2 potential-free contacts for end position feedback; incl. manual emergency override; incl. accumulator for safety position NC; torque 30Nm; operating time 8s; flange ISO5211 F03/F05-star 11mm; voltage 100...240VAC; protection class IP68
BA081-10-PH-01
Ball valve with electrical actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 1"; DN 25mm; Pressure range 0...40bar; Length 90mm; Operating time 9s; Voltage 100-240VAC; Body Actuator Aluminum Protection class IP68; Incl. Accumulator for safety position NC
BA668-14-S0
ball valve with pneumatic actuator; female thread; body, ball AISI 316Ti; seals POM/FKM; with erosion protection ring; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+100°C; for gases; G 1/4"; nominal diameter 6mm; pressure range 0...500bar; length 69mm; actuator PAS1005
BA668-14-0L
high pressure ball valve with electric actuator; female thread; body, ball AISI 316Ti; seals POM/FKM; with erosion protection ring; for gases; medium temperature -20...+100°C; G 1/4"; nominal diameter 6mm; pressure range 0...500bar; length 69mm; operating time 8s; voltage 24DC
BA668-14-0H
high pressure ball valve with electric actuator; female thread; body, ball AISI 316Ti; seals POM/FKM; with erosion protection ring; for gases; medium temperature -20...+100°C; G 1/4"; nominal diameter 6mm; pressure range 0...500bar; length 69mm; operating time 8s; voltage 100-240VAC
PAS0852
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 85mm; Flange ISO5211 F05/F07; Female square 17mm; Spring set 02; Torque at 4 bar 28,4Nm
BA582-38-D0
ball valve with pneumatic actuator; 3-way-type; sealing on three ports; female thread; body and ball stainless steel AISI 316Ti; seals POM/FPM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+100°C; G 3/8"; nominal diameter 10mm; pressure range 0...500bar; length 115mm; ball T; actuator PAD085
SQ052A-IA8-Q14-01
electrical actuator; suitable for valves with 90° operation; 2 potential-free contacts for end position feedback; 2 torque switches; incl. manual emergency override; torque 50-150Nm; operating time 8s; voltage 24VDC; protection class IP68; low temperature design -60...+70°C
BA670-10-S0-D
ball valve with pneumatic actuator series BA670-S-D; female thread; body AISI 316Ti; ball AISI 316Ti hard chrome plated; seals POM/NBR; with erosion protection ring; single acting actuator; control pressure 5,5...8bar; medium temperature -30...+100°C; G 1"; nominal diameter 25mm; pressure range 0...350bar; length 113mm; actuator PAS1405
BA868-38N-S0-AH
ball valve with pneumatic actuator; female thread; body, ball AISI 316L; seals PTFE-metal-reinforced EPDM special; single acting actuator; control pressure 5,5...8bar; medium temperature -45...+150°C; ambient temperature -40...+85°C; 3/8"NPT; nominal diameter 10mm; pressure range 0-100bar; length 52mm; actuator PAS0525-L; ATEX-design EX II 2 G-D T4
BA868-38N-T0-AH
ball valve with pneumatic actuator; female thread; body, ball AISI 316L; seals PTFE-metal-reinforced EPDM special; single acting actuator; control pressure 5,5...8bar; medium temperature -45...+150°C; ambient temperature -40...+85°C; 3/8"NPT; nominal diameter 10mm; pressure range 0-100bar; length 52mm; actuator PAS0525-LB; ATEX-design EX II 2 G-D T4; safety position NO
BA080-12-D0B-01
ball valve with pneumatic actuator; body, ball brass; seals PTFE/FKM/EPDM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1/2"; nominal diameter 15mm; pressure range 0-40bar; length 67mm; actuator PAD052-H
BA080-12-D0B-01-ABS51-C001-03-C002-31-6
BA080-12-D0B-01
ball valve with pneumatic actuator; body, ball brass; seals PTFE/FKM/EPDM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1/2"; nominal diameter 15mm; pressure range 0-40bar; length 67mm; actuator PAD052-H
ABS51
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
