Ball valve with pneumatic actuator; 3-way-type; T-bore; Sealing on two sides; Pressure inlet just in front; Female thread; Body 1.4571; Ball 1.4571 Hard chrome plated; Seals PEEK(ATEX)/FKM; With erosion protection ring For gases; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+85°C; Connection 1/2"NPT; Nominal diameter 13mm; Pressure range 0...500bar; Length 83mm; Actuator PAS1005; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1 For material And Additional High pressure gas test; Incl. ATEX-certificate

Ball valve with pneumatic actuator; 3-way-type; T-bore; Sealing on two sides; Pressure inlet just in front; Female thread; Body 1.4571; Ball 1.4571 Hard chrome plated; Seals PEEK(ATEX)/FKM; With erosion protection ring For gases; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+85°C; Connection 3/4"NPT; Nominal diameter 20mm; Pressure range 0...315bar; Length 95mm; Actuator PAS1255; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1 For material And Additional High pressure gas test; Incl. ATEX-certificate

Ball valve with pneumatic actuator; 3-way-type; T-bore; Sealing on two sides; Pressure inlet just in front; Female thread; Body 1.4571; Ball 1.4571 Hard chrome plated; Seals PEEK(ATEX)/FKM; With erosion protection ring For gases; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+85°C; Connection 1"NPT; Nominal diameter 25mm; Pressure range 0...315bar; Length 113mm; Actuator PAS1255; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1 For material And Additional High pressure gas test; Incl. ATEX-certificate

Ball valve with pneumatic actuator; 3-way-type; T-bore; Sealing on two sides; Pressure inlet just in front; Female thread; Body 1.4571; Ball 1.4571 Hard chrome plated; Seals PEEK(ATEX)/FKM; With erosion protection ring For gases; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+85°C; Connection 11/4NPT; Nominal diameter 32mm; Pressure range 0...420bar; Length 120mm; Actuator PAS1805; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1 For material And Additional High pressure gas test; Incl. ATEX-certificate

BA162-15-S0-A
Kugelhahn mit Druckluftdrehantrieb; ATEX II 2 G/D; Fire-Safe; TA-Luft; Baulänge gemäß EN558−1R101; Flansch PN100; voller Durchgang; Gehäuse und Kugel Edelstahl 1.4401; Dichtungen PTFE-metallverstärkt/Graphoil/FKM; Druckbereich 0...100bar;; einfachwirkender Antrieb; Steuerdruck 5,5...8bar; Mediumstemperatur -20...+160°C; Nennweite 15mm; Druckbereich 0...100bar; Einbaulänge 55mm; Antrieb PAS0755
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

ball valve with pneumatic actuator; ATEX II 2 G/D; fire-safe; TA-Luft; length according to EN558−1R101; flange PN100; full bore; housing and ball stainless steel AISI 316; seals PTFE-metal reinforced/Graphoil/FKM; pressure range 0...100bar;; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 15mm; pressure range 0...100bar; length 55mm; actuator PAS0755; free of oil and grease for hydrogen

Ball valve made of stainless steel Series BA168; ATEX II 2 G/D T4; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Body Polished; Seals PTFE/FKM; Medium temperature -20...+160°C; Connection 3/4"NPT; Nominal diameter 20mm; Pressure range 0...100bar; Length 72mm; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Flange ISO5211 F04; Square 11mm

Ball valve made of stainless steel Series BA168; ATEX II 2 G/D T4; Full bore; Two-parts type; Body, Ball 1.4404; Body Polished; Seals PTFE/FKM; Medium temperature -20...+160°C; Connection Double clamping ring 18mm; Nominal diameter 20mm; Pressure range 0...100bar; Length 72mm; Free of oil and grease for hydrogen; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Flange ISO5211 F04; Square 11mm

ball valve made of stainless steel series BA168; ATEX II 2 G/D T4; full bore; two-parts type; body, ball AISI 316L; body polished; seals PTFE/FKM; medium temperature -20...+160°C; connection Double clamping ring 18mm; nominal diameter 20mm; pressure range 0...100bar; free of oil and grease for hydrogen; flange ISO5211 F04; square 11mm

ball valve made of stainless steel; ATEX II 2 G/D; female thread; full bore; body AISI 316L polished; ball AISI 316L; seals PTFE/FKM; medium temperature -20...+170°C; connection 1"NPT; nominal diameter 25mm; pressure range 0...64bar; length 82mm; Oil and grease-free design for hydrogen and oxygen; ATEX II 2G Ex h IIC T4 Gb and II 2D Ex h IIIC T135°C Db

ball valve made of stainless steel; ATEX II 2 G/D; female thread; full bore; body AISI 316L polished; ball AISI 316L; seals PTFE/FKM; medium temperature -20...+170°C; connection 3/4"NPT; nominal diameter 20mm; pressure range 0...100bar; length 72mm; Oil and grease-free design for hydrogen and oxygen; ATEX II 2G Ex h IIC T4 Gb and II 2D Ex h IIIC T135°C Db

ball valve made of stainless steel; ATEX II 2 G/D; female thread; full bore; body AISI 316L polished; ball AISI 316L; seals PTFE/FKM; medium temperature -20...+170°C; connection 3/8"NPT; nominal diameter 10mm; pressure range 0...100bar; length 52mm; Oil and grease-free design for hydrogen and oxygen; ATEX II 2G Ex h IIC T4 Gb and II 2D Ex h IIIC T135°C Db

Ball valve made of stainless steel; Female thread; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals MPTFE/PTFE/FKM; Medium temperature -20...+60°C; G 11/4"; Nominal diameter 32mm; Pressure range 0...64bar; Length 92mm; Free of oil and grease for oxygen

Ball valve made of stainless steel; Female thread; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals MPTFE/PTFE/FKM; Medium temperature -20...+60°C; G 11/4"; Nominal diameter 32mm; Pressure range 0...64bar; Length 92mm; Free of oil and grease for oxygen; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
