BA162-15-S0-A-ABS53-C001-03-C002-31-6

BA162-15-S0-A-ABS53-C001-03-C002-31-6

BA162-15-S0-A
Kugelhahn mit Druckluftdrehantrieb; ATEX II 2 G/D; Fire-Safe; TA-Luft; Baulänge gemäß EN558−1R101; Flansch PN100; voller Durchgang; Gehäuse und Kugel Edelstahl 1.4401; Dichtungen PTFE-metallverstärkt/Graphoil/FKM; Druckbereich 0...100bar;; einfachwirkender Antrieb; Steuerdruck 5,5...8bar; Mediumstemperatur -20...+160°C; Nennweite 15mm; Druckbereich 0...100bar; Einbaulänge 55mm; Antrieb PAS0755
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 7.14 Kg
Short Itemnumber: BA16215S0AABS53C00103C002316

BA162-15-S0-A
Kugelhahn mit Druckluftdrehantrieb; ATEX II 2 G/D; Fire-Safe; TA-Luft; Baulänge gemäß EN558−1R101; Flansch PN100; voller Durchgang; Gehäuse und Kugel Edelstahl 1.4401; Dichtungen PTFE-metallverstärkt/Graphoil/FKM; Druckbereich 0...100bar;; einfachwirkender Antrieb; Steuerdruck 5,5...8bar; Mediumstemperatur -20...+160°C; Nennweite 15mm; Druckbereich 0...100bar; Einbaulänge 55mm; Antrieb PAS0755
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

1.128,20 € 1128.2 EUR 1.128,20 €
