Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA747-12N-S0
ball valve with pneumatic actuator; female thread; housing AISI 316Ti; ball Nitronic-50; seals PEEK/FPM (AED); single acting actuator; control pressure 5,5...8bar; medium temperature -40...+85°C; 1/2"NPT; nominal diameter 13mm; pressure range 0...1000bar; actuator PAS1255
BA053-80-072-01
Flanged ball valve with electrical actuator; Protection class IP68; 3-way-type; Sealing on two sides; Pressure inlet just in front; Reduced bore; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 80mm; DN ball 64mm; Length 122mm; Ball L; Actuator AUMA SQ05.2; Operating time 16s; Voltage 400V 50Hz 3-ph AC
BA056-80-0L
Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 80mm; Length 260mm; Pressure range 0…16bar; Flange PN16; Ball T; Operating time 27s; Voltage 24VAC/DC
SQ72A-EB8-Q22-02
Electric control actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; 2 Torque switches; Incl. manual emergency override; Torque 100-300Nm Adjustable; Operating time 8 Seconds; Flange ISO5211-F07/F10; Square 22mm; Voltage 230V/50Hz; Protection class IP68; class C EN15714-2, S4 25%; Incl. Aumamatic AC 01.2
BA049-150-0H-U
Flanged ball valve with electrical actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; DN 150mm; Pressure range 0-16bar; Length 232mm; Operating time 50s; Voltage 100-240VAC; Protection class IP67; With UL-Approval; UNC-Thread
BA056-80-0H
Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Medium temperature -20...+160°C; Nominal diameter 80mm; Length 260mm; Pressure range 0…16bar; Flange PN16; Ball T; Operating time 27s; Voltage 100-240VAC
BA082-150-D2
Flanged ball valve with pneumatic actuator; Flange ANSI150; Body, Ball 1.4401; Seals PTFE/FKM; Double acting actuator; Control pressure 4...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 150mm; Length 232mm; Actuator PAD160
ERE026
Flanged ball valve with pneumatic actuator; Flange PN16; Body Cast iron EN-GJL-250; Ball 1.4301; Seals PTFE/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+120°C; Pressure range 0...16bar; Nominal diameter 200mm; Length 400mm; Length EN558-1 R27; Special version: Actuator PAD180; Incl. 5/2-way pilot valve And Incl. coil SCN 24VDC; Pilot valve mounted rotated by 180 ° NO
BA716-50-D0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T6 X; Body, Ball 1.4401/1.4542; Seals Metallic/Graphoil; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -46...+400°C; Nominal diameter 50mm; Pressure range 0...40bar; Flange PN40; Actuator PAD115-H; Incl. 100mm Stem extension
PFQ150-CF320-Q14
Electric control actuator; Max. torque 150Nm; Operating time 8...320 Seconds; Flange ISO5211-F05/F07/F10; AF 14mm; Voltage 100...240VAC; Protection class IP67; Position feedback 0/4-20mA / 0-10V
BA110-150-D0
Flanged ball valve with pneumatic actuator; Fire-Safe/Antistatik According to ATEX/TA−Luft; Length According to EN558−1 R27; Body, Ball 1.4408; Ball seal PTFE-graphite reinforced; Stem seal Graphoil/FKM/PTFE; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+198°C; Nominal diameter 150mm; Pressure range 0-15bar; Flange PN16; Length 350mm; Actuator PAD125
BA051-150-D0-01
Flanged ball valve with pneumatic actuator; Fire-Safe/Antistatik According to ATEX/TA−Luft; Length According to EN558−1 R27; Body, Ball 1.4408; Stem seal 2-fold PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 150mm; Pressure range 0-16bar; Flange PN16; Length 350mm; Actuator PAD140
SQ72A-EM8-Q22-01
Electric control actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; 2 Torque switches; Incl. manual emergency override; Torque 100-300Nm Adjustable; Operating time 8 Seconds; Flange ISO5211-F07/F10; Square 22mm; Voltage 400V50Hz; Protection class IP68; class C EN15714-2, S4 25%; ATEX II 2G Ex db eb IIC T4 Gb; II 2D Ex tb IIIC T130°C Db; II 2G Ex h IIC T4 Gb; Incl. Aumamatic ACEXC 01.2
BADA-150-SSTV-D0A
Flanged ball valve DN150, PN16 body and ball 1.4401, seal PTFE/FKM, ATEX with double-acting pneumatic actuator 160-ATEX
BA741-50-0N
flanged ball valve with electrical actuator; ball valve ATEX II 2 G/D c T6 X; housing AISI 316; ball AISI 316/CRC-coated; seals metallic CRC-WC/graphite; stem inconel 718; medium temperature -46...+400°C; nominal diameter 50mm; pressure range 0...40bar; flange PN40; length 100mm; incl. 100mm stem extension; actuator VS300; operating time 60s; voltage 15-30V/50-60Hz, 12-48VDC
VT1500-0V155-Q46
electrical actuator; suitable for valves with 90° operation; for a maximum of 100 operations a day; limit switch-off is wired; 2 potential-free contacts for end position feedback; incl. manual emergency override; torque 1500Nm; operating time 155sec; flange ISO5211 F12/F16-star 46mm; voltage 24-48V/50-60Hz, 24-72VDC; protection class IP68
SQ25-CB50-Q17-01
Electric control actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; 2 Torque switches; Incl. manual emergency override; Torque 250Nm; Operating time 50 Seconds; Flange ISO5211-F07/F10; AF 17mm; Voltage 230V50Hz; Protection class IP67; Class III; Positioner Minigam+; Input signal 4-20mA Or 0...10V; Outlet signal 4…20mA
BA050-150-T0
Flanged ball valve; Flange PN16; Full bore; Body; Ball 1.4401; Seals PTFE-Graphite/FKM; Nominal diameter 150mm; Length 232mm; Steam applications Max. 15bar/198°C; Single acting actuator; Control pressure 5,5...8bar; Actuator PAS2005; Safety position Open
BA044-150-0C-A
Flanged ball valve with electrical actuator; Fire-safe; TA-Luft; Length According to EN558−1R27; Body Zinc plated steel; Ball 1.4301; Seals PTFE/Graphoil/FKM; Medium temperature -10...+160°C; Nominal diameter 150mm; Pressure range 0...16bar; Flange PN16; Length 350mm; Operating time 38s; Voltage 230V/50-60Hz; Actuator VTX600; Protection class IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; 2 potential-free contacts for end position feedback; Incl. manual emergency override
SQ07.2A-0M8-Q22-01
Electrical actuator; AUMA NORM SQ07.2; Flange: F10; AF22; Voltage 400V/50Hz; 3-phase; Protection class IP68; Operating time 8 Seconds; 100...300Nm; Connection plan 00R1AA-101-000
