Ball valves - automatically operated

Electrical actuator; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Protection class IP68; ATEX II 2 G/D ExdIIBT6Gb ExtbIIICT80°CDb; Torque 300Nm; Operating time 35s; Flange ISO5211 F07/F10-star 22mm; Voltage 400V/50-60Hz;

BA625-100-S0

Flanged ball valve with pneumatic actuator; Flange PN16; Body Ductile iron; Seals PTFE/FPM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10…+60°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 190mm; TA-Luft certification; DVGW-gas-approved

BAA1-011-SSCV-S0A

Ball valve with pneumatic rotary actuator 12505 G 3", PN25, body and ball 1.4401, seal PTFE/FKM ATEX antistatic connection RP3"

BA055-32-0L

Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Body 1.4404 Polished, Ball 1.4404; Seals PTFE/FKM; Full bore; Medium temperature -20...+160°C; Nominal diameter 32mm; Length 180mm; Pressure range 0...40bar; Flange PN40; Operating time 9s; Voltage 24V50-60Hz/DC; Ball L

BA622-50-D0

Ball valve with pneumatic actuator; Flange PN63; According to ATEX Body, Ball 1.4401; Seals fibre-glass-reinforced PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...63bar; Nominal diameter 50mm; Length 100mm; Actuator PAD063

SQ15-0M15-Q17

Electrical actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 150Nm; Operating time 15s; Flange ISO5211-F05/F07-Square 17mm; Voltage 400V50Hz; Protection class IP67

BA033-20-0F-A

ball valve with electrical actuator; ATEX II 2 G/D; TA-Luft; female thread; body, ball AISI 316; seals PTFE/FKM; medium temperature -20...+160°C; RP 2"; DN 50mm; pressure range 0-25bar; length 136mm; electrical actuator VRX75; operating time 20s; <Protection class IP68; ATEX II 2 G D Ex db IIB T6 Gb Ex tb IIIC T80°C Db; voltage 100-240V/50-60Hz; 100-350VDC

BA591-40-B

Flanged ball valve; Bare shaft; 3-way-type; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/Kalrez; Sealing on three ports; Medium temperature -40...+160°C; Nominal diameter 40mm; Length 200mm; Flange PN40; Pressure range 0-40bar; Ball T; Flange ISO5211 F05; Square 14mm

BA701-10-S0-0

ball valve with pneumatic actuator; female thread; housing AISI 316Ti; ball AISI 316Ti hard chrome plated; seals PEEK/FKM; with erosion protection ring; for gases; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+200°C; G 1"; nominal diameter 25mm; pressure range 0...350bar; length 113mm; actuator PAS1405; free of oil and grease for oxygen

BA243-12-0N-A-01

High pressure ball valve With electric actuator; Female thread; Body, Ball 1.4571/1.4404; Seals PEEK-Natural/FKM (AED); Medium temperature -40...+200°C; G1/2"; DN 13mm; Pressure range 0-500bar; Length 83mm; Free of oil and grease; Voltage 15-30V/50-60Hz; 12-48VDC; Operating time 20 Seconds; Actuator VRX75; IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb

BA082-80-S0

Flanged ball valve with pneumatic actuator; Flange ANSI150; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 122mm; Actuator PAS1255

BA082-80-T0

BA494-14N-B-H3N-01

high pressure ball valve; female thread; drilled for mounting an actuator; body AISI 316Ti; ball Nitronic-50; seals PEEK/FKM-special version /PTFE; medium temperature -40...+85°C; connection 1/4"NPT; nominal diameter 8mm; pressure range 0...650bar; free of oil and grease for hydrogen; incl. inspection certificate EN-10204-3.1 for material and Special test with forming gas (95% nitrogen (N2)/5% helium (He)); flange ISO5211 F07; square 22mm

BA055-32-T0

Flanged ball valve with pneumatic actuator; Flow path 05; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 32mm; Length 180mm; Pressure range 0...40bar; Flange PN40; Actuator PAS1005-A; Ball L; Inverse direction of rotation

6DR5010-0NN00-0AA0

I/P-positioner For single acting actuators; Sipart PS2; Inlet 4-20mA

BA688-50-B

Ball valve made of stainless steel; PN160, Butt weld ends; Body, Ball, Stem Stainless steel; Seals Fibre-glass-reinforced PTFE/FFKM; Pressure range 0…160bar; Nominal diameter 50mm; ISO-Flange F07 For mounting an actuator; Square 17mm

BA179-50-S0-A-01

Ball valve with pneumatic actuator; ATEX II 2G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R101; Flange PN100, Full bore; Body steel A350-LF2, Ball 1.4301; Seals PTFE-metal reinforced/FKM/Graphite; Pressure range 0...100bar; Single acting actuator ATEX II 2G/D c T6; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; Pressure range 0...100bar; Length 100mm; Actuator PAS1155; Incl. Mounted solenoid valve ABS53-24VDC

BA392-100-0H

Flanged ball valve with electrical actuator; Length According to EN558−1R27; Body Steel A352-LCB; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; DN 100mm; Pressure range 0-16bar; Flange PN16; Length 190mm; Operating time 27s; Voltage 100-240VAC

BA048-100-D0

Flanged ball valve with pneumatic actuator; Flange PN16; Body, Ball 1.4301; Seals PTFE/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 152mm; Actuator PAD100

PSQ503-0C93-Q22-01

Electrical actuator; Suitable for Valves with 90° operation; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 600Nm; Operating time 93s; Flange ISO5211-F10; Square diagonal 22mm; Voltage 230V-50/60Hz; Protection class IP67
