Ball valves - automatically operated

STASTO Allgemeine Preisliste (EUR)
BA559-65-D0
Flanged ball valve with pneumatic actuator; Flange PN250; Body Zinc plated steel, Ball And Stem Stainless steel; Seals POM/NBR; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+60°C; Pressure range 0...250bar; Nominal diameter 65mm; Length 200mm; Actuator PAD180
BA561-50-B
Flanged ball valve; Length According to EN558−1 F1; Full bore; Body And Ball 1.4571; Seals PEEK/Special seals; Medium Steam; Medium temperature Max. 230°C; Nominal diameter 50mm; Pressure range 0-25bar; Flange PN40; Length 230mm; For mounting an actuator F05/SW17-126Nm
BA562-15L-L
High pressure ball valve; Male thread According to DIN 2353; Body, Ball Steel; Seals PTFE/FKM; Medium temperature -20...+60°C; Connection 15L/M22x1,5; Nominal diameter 12mm; Pressure range 0-40bar; Length 96mm; Actuation Hand lever; DVGW
BA569-100-D0
Flanged ball valve with pneumatic actuator; Flange PN16; Material PVC-U; Seals PTFE/EPDM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature 0...+60°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 350mm; Actuator PAD085
BA569-80-D0
Flanged ball valve with pneumatic actuator; Flange PN16; Material PVC-U; Seals PTFE/EPDM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature 0...+60°C; Pressure range 0...16bar; Nominal diameter 80mm; Length 310mm; Actuator PAD075
BA572-50-D0-3C
Ball valve with pneumatic actuator; Butt weld ends; Body, Ball 1.4408; Seals PTFE-reinforced/FKM; Antistatic; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 50mm; ; Length 150mm; Pressure range 0-64bar; Actuator PAD063; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
BA575-100-T0
Flanged ball valve with pneumatic actuator; Flange PN40; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -35...+150°C; Pressure range 0...40bar; Nominal diameter 100mm; Length 152mm; Actuator PAS1805; Safety position NO
BA575-25-S0-A
Flanged ball valve with pneumatic actuator; Flange PN40; Antistatic design; ATEX II 2 G/D c T3; Body, Ball 1.4401; Seals PTFE-reinforced/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -30...+150°C; Pressure range 0…40bar; Nominal diameter 25mm; Length 46mm; Actuator PAS0855
BA578-114-D0
High pressure ball valve With Pneumatic actuator; Double acting; 4-way-type; Female thread; Stainless steel; Seals PEEK/FKM; Medium temperature -20...+200°C; G 11/4"; Nominal diameter 25/32mm; Pressure range 0-315bar; X-bore; Control pressure 5,5...8bar
BA578-34-D0
Ball valve With Pneumatic actuator; Double acting; 4-way-type; Female thread; Stainless steel; Seals PEEK/FKM; Medium temperature -20...+200°C; G 3/4"; Nominal diameter 20mm; Pressure range 0-16bar; X-bore; Control pressure 5,5...8bar
BA580-12-B
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 1/2"NPT; Nominal diameter 15mm; Length 82mm; Pressure range 0-40bar; Ball L; For mounting an actuator F03/9mm
BA580-12-B-A
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 1/2"NPT; Nominal diameter 15mm; Length 82mm; Pressure range 0-100bar; Ball L; For mounting an actuator F03/9mm; ATEX-design
BA580-12-S0
Ball valve with pneumatic actuator; 3-way-type; Ball is sealed on all sides; Body 1.4404 Polished; Ball 1.4404; Seals PTFE; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Female thread 1/2NPT"; Nominal diameter 15mm; Pressure range 0...40bar; Length 82mm; Actuator PAS0755; Ball L
BA580-12-S0-A
Ball valve with pneumatic actuator; 3-way-type; Ball is sealed on all sides; Body 1.4404 Polished; Ball 1.4404; Seals PTFE; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Female thread 1/2NPT"; Nominal diameter 15mm; Pressure range 0...40bar; Length 82mm; Actuator PAS0755; Ball L; ATEX-design
BA580-14-B
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 1/4"NPT; Nominal diameter 12mm; Length 72mm; Pressure range 0-40bar; Ball L; For mounting an actuator F03/9mm
BA580-14-B-A
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 1/4"NPT; Nominal diameter 12mm; Length 72mm; Pressure range 0-40bar; Ball L; For mounting an actuator F03/9mm; ATEX-design
BA580-14-S0
Ball valve with pneumatic actuator; 3-way-type; Ball is sealed on all sides; Body 1.4404 Polished; Ball 1.4404; Seals PTFE; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Female thread 1/4NPT"; Nominal diameter 12mm; Pressure range 0...40bar; Length 72mm; Actuator PAS0755; Ball L
BA580-14-S0-A
Ball valve with pneumatic actuator; 3-way-type; Ball is sealed on all sides; Body 1.4404 Polished; Ball 1.4404; Seals PTFE; Single acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Female thread 1/4NPT"; Nominal diameter 12mm; Pressure range 0...40bar; Length 72mm; Actuator PAS0755; Ball L; ATEX-design
BA580-34-B
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 3/4"NPT; Nominal diameter 20mm; Length 92mm; Pressure range 0-40bar; Ball L; For mounting an actuator F05/14mm
BA580-34-B-A
Ball valve made of stainless steel; 3-way-type; Ball is sealed on all sides; Full bore; Body, Ball 1.4401; Seal PTFE; Medium temperature -20...+160°C; Female thread 3/4"NPT; Nominal diameter 20mm; Length 92mm; Pressure range 0-40bar; Ball L; For mounting an actuator F05/14mm; ATEX-design
